Gearbox
Number of longitudinal feeds
Range of longitudinal feeds
Number of inch threads
Range of inch threads
Number of metric threads
Range of metric threads
Compound and Carriage
Tool post type
Maximum tool size
Maximum compound slide travel
Maximum cross slide travel
Maximum carriage travel
Tailstock
Tailstock spindle travel
Diameter of tailstock spindle
Taper in tailstock spindle
Main materials
Headstock
Bed
Apron/Saddle
Tailstock
Splash guard
Dimensions
Bed width
Overall dimensions (LxWxH)
Shipping dimensions (LxWxH)
Weights
Net weight (approx.)
Shipping weight (approx.)
1
subject to local and national electrical codes.
2
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As workplace
conditions vary, this information is intended to allow the user to make a better estimation of the hazards and risks
involved only.
L = length, W = width, H = height, TPI = threads per inch
n/a = not applicable
The specifications in this manual were current at time of publication, but because of our policy of continuous
improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring
obligations.
BDB-919
60
0.0006 – 0.037 in.
27
8 – 56 TPI
12
0.5 – 3.5 mm
Single and 4-way
1/2 x 1/2 in.
1-7/8 in.
4-1/4 in.
17-1/2 in.
1-9/16 in.
1-1/6 in.
MT-2
Cast iron
Cast iron
Cast iron
Cast iron
Steel
4-1/2 in.
41 x 22 x 20 in.
41 x 22 x 22 in.
250 lbs
293 lbs
8
BDB-929
26-1/2 in.
51 x 22 x 20 in.
51 x 22 x 22 in.
287 lbs
344 lbs
