BUILT IN REFRIGERATOR
EN
User manual
MICR122

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MICR122 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for montpellier MICR122

Summary of Contents for montpellier MICR122

  • Page 1 BUILT IN REFRIGERATOR User manual MICR122...

  • Page 2: Table Of Contents

    Index BEFORE USING THE APPLIANCE ..........3 General warnings ..............3 Old and out-of-order fridges ............5 Safety warnings ...............5 Installing and operating your fridge freezer ......6 Electrical connection (For UK type plug) .........7 Before using your fridge freezer ..........7 HOW TO OPERATE THE APPLIANCE ........8 Thermostat setting ..............8 Warnings about temperature adjustments ......8 Ice tray .......................9...

  • Page 3: Before Using The Appliance

    PART 1. BEFORE USING THE APPLIANCE General warnings WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
  • Page 4 - bed and breakfast type environments; - catering and similar non-retail applications. • If the socket does not match the refrigerator plug, it must be replaced by the manufacturer, a service agent or similarly qualified persons in order to avoid a hazard. •...

  • Page 5: Old And Out-Of-Order Fridges

    Old and out-of-order fridges • If your old fridge has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore, take care not to harm environment when you are discarding your old fridges.

  • Page 6: Installing And Operating Your Fridge Freezer

    • Never touch the power cord/plug with wet hands as this could cause a short circuit or electric shock. • Do not place glass bottles or beverage cans in the ice-making compartment as they can burst as the contents freeze. •...

  • Page 7: Electrical Connection (For Uk Type Plug)

    • Use the adjustable front legs to make sure your appliance is level and stable. You can adjust the legs by turning them in either direction. This should be done before placing food in the fridge freezer. • Before using your fridge freezer, wipe all parts with a solution of warm water and a teaspoon of sodium bicarbonate, then rinse with clean water and dry.

  • Page 8: How To Operate The Appliance

    PART 2. HOW TO OPERATE THE APPLIANCE Thermostat setting Thermostat automatically regulates the inside temperature of the fridge compartment and freezer compartment. By rotating the knob from position 1 to 5, colder temperatures can be obtained. Important note: Do not try to rotate knob beyond 1 position it will stop your appliance.

  • Page 9: Ice Tray

    “Door Open” Indicator; • The “Door Open” indicator on the lock slide indicates whether the door is closed properly or not. • If the red indicator is visible, the door is still open. • If the red indicator is invisible, the door is properly closed. •...

  • Page 10: Cleaning And Maintenance

    • When storing frozen food; the instructions shown on frozen food packaging should always be followed carefully and if no information is provided, food should not be stored for more than 3 months from the purchase date. • When buying frozen food ensure that these have been frozen at suitable temperatures and that the packing is intact.

  • Page 11: Defrosting

    Defrosting Defrosting the fridge compartment: • Defrosting occurs fully automatically in refrigerator compartment during operation; the defrosted water collected by the evaporating tray and evaporates automatically. • The evaporating tray and water drain hole (back of the refrigerator crisper shelf) should be cleaned periodically to prevent the water from collecting on the bottom of the refrigerator instead of flowing out.

  • Page 12: Replacing The Light Bulb

    Replacing the Light bulb When replacing the bulb of the fridge compartment; 1. Unplug the unit from the power supply, 2. Press the hooks on the sides of the light cover top and remove the light cover 3. Change the present light bulb with a new one of not more than 15 W. 4.
  • Page 13 What to do if your refrigerator performs poorly Check that: • You have not overloaded the appliance, • The doors are closed properly, • There is no dust on the condenser, • There is enough place at the rear and side walls. If there is noise: The cooling gas which circulates in the refrigerator circuit may make a slight noise (bubbling sound) even when the compressor is not running.

  • Page 14: Tips For Saving Energy

    Tips For Saving Energy 1. Install the appliance in a cool, well ventilated room , but not in direct sunlight and not near a heat source (radiator, cooker.. etc). Otherwise use an insulating plate. 2. Allow warm food and drinks to cool down outside the appliance. 3.

  • Page 15: Parts Of The Appliance And The Compartments

    PART 7. PARTS OF THE APPLIANCE AND THE COMPARTMENTS This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. 1) Freezer compartment & Freezer door 8) Door midle shelves 2) Ice tray 9) Egg holder 3) Fridge compartment shelves 10) Butter-Cheese shelf...

  • Page 16: Installation Instructions And Door Reversibility

    Installation instructions and door reversibility Installation ! Before installation, read the instructions carefully. ! Fit the refrigerator/freezer in stable kitchen units only. ! If necessary, reverse the door according to instructions. 1. See fig.A for the necessary attachment components. 2. Insert trim flap into slot and screw by screws .
  • Page 17 1225 1225 - 1245 Figure A Figure C Figure B Figure E Figure D EN -17-...
  • Page 18 Figure F Figure G Figure H EN -18-...
  • Page 19 Figure J Figure K Door reversing 1. Open appliance door and freezer door . (fig.J) 2. Disassemble freezer door hinge and take freezer door to safe place. (fig.J) 3. Disassemble freezer door lock and assemble it to opposite side.(fig.J) 4. Position freezer door to keep handle close to freezer door lock and insert its upper axes into cabinet hole / lower axes into freezer door hinge12 and then assemble freezer...
  • Page 20 Repairtech Service Helpline: 01527-888133 DOMESTIC APPLIANCE DISTRIBUTORS; HENRY JOHN HOUSE NORTHWAY LANE ASHCHURCH TEWKESBURY GLOUCESTERSHIRE 52206297 GL20 8JH...
