- Page 1 BUILT IN LARDER User manual MICL122...
-
Page 2: Table Of Contents
Index BEFORE USING THE APPLIANCE ..............2 Old and out-of-order fridges ..................... 4 Safety warnings ........................4 Installing and operating your fridge ................. 5 USAGE INFORMATION ..................7 Thermostat Setting ......................7 Warnings for Temperature Settings ................. 7 ARRANGING FOOD IN THE APPLIANCE ............8 CLEANING AND MAINTENANCE ............... -
Page 3: Before Using The Appliance
CHAPTER 1. BEFORE USING THE APPLIANCE General warnings WARNING: Keep vantilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. - Page 4 - farm houses and by clients in hotels, motels and other residential type environments. - bed and breakfast type environments; - catering and similar non-retail applications. • If the socket does not match the refrigerator plug, it must be replaced by the manufacturer, a service agent or similarly quali- fied persons in order to avoid a hazard.
-
Page 5: Old And Out-Of-Order Fridges
Old and out-of-order fridges • If your old fridge has a lock, break or remove the lock before discarding it, because children may get trapped inside it. • Old fridges and freezers may contain isolation material and refrigerant with CFC or HFC. Therefore, take care not to harm environment when you are discarding your old fridges. -
Page 6: Installing And Operating Your Fridge
• When removing ice from the ice-making compartment, do not touch it. Ice may cause frost burns and/or cuts. • Do not touch frozen goods with wet hands! Do not eat ice-cream and ice cubes immediately after you have taken them out of the freezer department! •... -
Page 7: Before Using Your Fridge
• Before using your fridge, wipe all parts with a solution of warm water and a teaspoon of sodium bicarbonate, then rinse with clean water and dry. Place all parts in the fridge after cleaning. • Install the plastic distance guide (the part with black vanes at the rear) by turning it 90°... -
Page 8: Usage Information
CHAPTER 2. USAGE INFORMATION Thermostat Setting Larders (coolers) do not have a freezer compartment but can cool below 5°C. • The thermostat automatically regulates the inside temperature of the refrigerator compartment. By rotating the knob from position « 1 » to « 5 », colder temperatures can be obtained. -
Page 9: Arranging Food In The Appliance
the refrigerator, and the environment in which the refrigerator is located. • Your fridge should be operated up to 24 hours according to the ambient temperature without interruption after being plugged in to be completely cooled. Do not open doors of your fridge frequently and do not place much food inside it in this period. -
Page 10: Cleaning And Maintenance
CHAPTER 4. CLEANING AND MAINTENANCE • Disconnect the unit from the power supply before cleaning. • Do not clean the appliance by pouring water. • Make sure that no water enters the lamp housing and other electrical components. • The refrigerator should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water. -
Page 11: Defrosting The Refrigerator Compartment
Defrosting the Refrigerator Compartment • Defrosting occurs automatically in the refrigerator compartment during operation; the water is collected by the evaporation tray and evaporates automatically. • The evaporation tray and the water drain hole should be cleaned periodically with the defrost drain plug to prevent the water from collecting at the bottom of the refrigerator instead of flowing out. -
Page 12: Transportation And Changing Of Installation Position
TRANSPORTATION AND CHANGING OF CHAPTER 5. INSTALLATION POSITION Transportation and Changing of Installation Position • The original packages and foamed polystyrene (PS) can be retained if required. • During transportation, the appliance should be secured with a wide string or a strong rope. -
Page 13: Tips For Saving Energy
If your fridge is not cooling sufficiently enough: Your fridge is designed to operate in the ambient temperature intervals stated in the standards, according to the climate class stated in the information label. W e do not recommend operating your fridge out of stated temperatures value limits. This will reduce the cooling efficiency of the fridge. -
Page 14: The Parts Of The Appliance And The Compartments
THE PARTS OF THE APPLIANCE AND THE CHAPTER 7. COMPARTMENTS This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. 1) Thermostat box 5) Left & Right feet 2) Refrigerator shelves 6) Bottle shelf 3) Crisper cover (Safety glass) 7) Door shelf... - Page 15 ELECTRICAL CONNECTION (FOR UK TYPE PLUG) For your safety please read the following information Warning: This appliance must be earthed. This appliance operates from 220-240 volts and should be protected by a 13 amp fuse in the plug. The appliance is supplied with a standard 13 amp 3-pin mains plug fitted with a 13-amp fuse. Should the fuse require replacement, it must be replaced with a fuse rated at 13 amp and approved to BS1362.
- Page 16 Repairtech Service Helpline: 01527-888133 DOMESTIC APPLIANCE DISTRIBUTORS; HENRY JOHN HOUSE NORTHWAY LANE ASHCHURCH TEWKESBURY GLOUCESTERSHIRE 52206294 GL20 8JH...
