Installation
How To Remove And Install The Front Panel
When detaching or attaching the control panel, be careful not to damage the
connectors on the back of the control panel and on the panel holder.
Detaching The Front Panel
Before detaching the control panel, be sure to turn off the power.
1). Press the release button and the left hand side of the front panel will release.
(FIG. 1)
2). Pull-off the front panel (FIG. 2) and keep the front panel into the case (FIG. 3)
Attaching The Front Panel
1). First insert the right hand side of the front panel into the hollow of the unit .
2). Gently push the left hand side of the front panel until you feel a " Click" .
and then press the PWR button (2) briefly to switch the device ON.
FRONT PANEL
RELEASE BUTTON
FIG.1
PROTECTIVE CASE
FRONT PANEL
FIG.3
FRONT PANEL
Attaching The Front Panel
7
FIG.2
FIG.4
