  • Page 2 PRECAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightening flash with arrowhead symbol, within an equilateral triangle, i s intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

  • Page 3: Table Of Contents

    6. Specification General Specification Power Supply Requirement...DC 12V Maximum Power Output...4 x 80W(measured at DC 14.4 V) Dimensions(w x h x d)...178 x 50.5 x 162mm DVD Deck Specification Format...DVD/VCD/JPEG/MP4/MP3/WMA/CD Video System...NTSC/PAL/PAL-M/PAL-N/AUTO(optional) Audio System...24 bit/96KHz Loading System..Auto Loading Mounting Angle...0 to +/-30 Video Specification...

  • Page 4: Before Operation

    1. Before Operation 1.1 Glossary PBC (playback control) It is a kind of signal(menu) recorded in the disc with SVCD or VCD2.0 format used for the playback control. For the discs contained PBC, It can playback interactive software with the menu displayed on monitor screen. If the disc contain still images, it can playback high definition of still image.

  • Page 5: Maintenance And Cleaning Of Discs

    The Region Code Q: Not begin to playback but to display REGION ERROR after inserting disc into disc compartment. Why ? A: Because the DVD player and disc has respective region code. If the region codes of them are not match with each other, the DVD player can not play the disc. Appendix: The region code of DVD: The Motion Picture Association of America (MPAA) divided the world into 6 regions, and named every region a code, namely region code.

  • Page 6: The Remote Control Description

    1.5 The Remote Control Description BAND MODE MENU SETUP 0/10 SLOW_FWD SEARCH ZOOM AUDIO TITLE/PBC SUBTITLE PROG LOUD STEP 16. SEARCH BUTTON 17. RDM BUTTON 18. RPT BUTTON 19. SUBTITLE BUTTON 20. TITLE/PBC BUTTON 21. ANGLE/ST BUTTON 22. ZOOM BUTTON 23.

  • Page 7: The Locations And Names Of Controls On Or In The Unit

    4.24.2 LANGUAGE SETUP OSD LANGUAGE This item is for selecting the language of the SYSTEM MENU and all operating prompt interface displayed during playback. AUDIO LANG This item is for selecting a audio language. SUBTITLE LANG This item is for selecting a subtitle language. MENU LANG This item is for selecting a disc menu language.

  • Page 8: Wires Connection Description

    1.7 Wires Connection Description The Description of the Input/Output Interface of the Rear Cabinet Fixed ISO Female Connector Clip of the other wires The Description of the Other Wires Through the Clip VIDEO OUT2 AUX IN-V CAMERA AUX IN-R AUX IN-L VIDEO OUT1 PARKING REVERSE Radio Ant...

  • Page 9: Unit Installation

    3. During IMAGE playback, press one of the >/</^/v buttons to change the angle of viewing picture that is displaying as follows: >: 90 deg cw; <: 90deg ccw; ^:UP<-->DOWN; v: LEFT<-->RIGHT During IMAGE playback, press the PROG button to change the mode of refresh picture. During IMAGE playback, press the STOP button to stop playing and return to the root menu.

  • Page 10: Common Operation

    2. Common Operation 1. To turn on/off the unit In power off mode, short press the POWER button to turn on the unit. In power on mode, long press the POWER button on the front panel or short press the POWER button on the remote control to turn off the unit. 2.

  • Page 11: Radio Operation

    ZOOMx2,ZOOMx3,ZOOMx4,ZOOMx1/2,ZOOMx1/3,ZOOMx1/4,ZOOM OFF. Press one of the ^/v/>/< buttons to select the area you want to enlarge. 4.16 Change the Caption Language In the state of DVD playing, press the SUBTITLE button repeatedly to select the language of the caption or turn off the caption.(depend on the media used.) In the state of VCD/MP3/WMA/CD playing, the button is not available.

  • Page 12: Disc, Usb And Card Operation

    finishing a circle of scanning , it will resume broadcasting on the M1.(It can store 3x6 stations for FM and 2x6 stations for AM in all) 2) When briefly pressing the APS button, the radio will scan each preset station for 5 seconds in FM or AM band from M1.

  • Page 13: Playback Repeatedly

    During slow forward, press the PLAY button to resume normal playback. The function is only for video. 4.9 Display still frame step by step If the unit is currently playing video, press the TEL button consecutively to display still frame step by step. Press the PLAY button to resume normal playback.

  • Page 14: Pause Playback

    4.2 Pause Playback In the state of DVD/VCD/CD/MP3/WMA playing, press the PAUSE button on IR remote control to pause the playback, press the PLAY button to resume normal playback. .3 Stop Playback In the state of DVD/VCD/MP3/WMA/CD playing, press the STOP button once to pause the playback, then press the PLAY button to resume the normal playback;...
