- Page 1 User’s Manual PLDNAND465 Android Stereo Receiver & Dual Camera System HD DVR Dash Cam, Rearview Backup Camera, 6.5'' Touchscreen Display, Wi-Fi Web Browsing, App Download, GPS Navigation, Bluetooth Streaming, HD 1080p Support, Double DIN...
-
Page 2: Table Of Contents
System descriptions and features re ected as herein stated by this user manual serves to express the Pyle Audio Headunit Receiver features at the current production period. We reserve the right to change terms and conditions of system speci cations, features and descriptions at any time, as we continue to improve and provide our customers with upgrades in safety, performance and system operation in general. -
Page 3: Precautions 3
COMPATIBILITY This unit is a standard “Double Din” sized radio. Check to see that your vehicle accepts a double din sized radio. This unit conforms to the standard size and dimensions of a double din radio. Your vehicle may require a vehicle speci c or 3rd. - Page 4 SYSTEM INSTALLATION: Before starting: To prevent short circuits, be sure to disconnect the battery terminal before starting. Installation Guide - Double Din Fitting: Caution: 1. This screen opens up. Install the unit within 30 degrees of the horizontal plane. Check that the screen has enough room to fully open.
- Page 5 This unit has the ability to wire directly to your vehicle’s steering wheel column and does not, but may, require a 3 party steering wheel control interface. Pyle Audio Technical support can assist you in interfacing into vehicles with existing steering wheel controls. For additional help, contact Pyle Technical Support and be sure to supply Year Make Model and options of vehicle so that proper instructions can be supplied.
-
Page 6: Front Panel And Buttons
FRONT PANEL AND BUTTONS R ST Hold to open screen and eject disk. Return Switch between apps/radio interface, Press while in GPS interface to return to radio apps Volume up Volume down Hold to power up Use a pin to insert into reset port to trigger unit reset. (Hold for 20 secs . to reset) Tips: Navi----You might have several maps in this device, by pressing Navi button, you will enter into the map which you set as default in the Navi path, if you want to change the navi path to another map, please go to setting to change it. -
Page 7: Settings
*Please Note: - Navigation and CD/DVD options and applications may only be found in select head unit receiver stereo systems, which include these, and other, additional/special features -- not all Pyle stereo models come equipped with GPS Navigation and/or CD/DVD players. -
Page 8: Set Time
SETTINGS 1. Scrolling Use the red bar to scroll through the list of all available options. 2. Turn on/o Many settings can be toggled on or o in this screen *Note: Factory setup is not adjustable by user. Do not attempt to enter this setup menu. SET TIME 1. - Page 9 CALENDAR • Displays the day, month and year. • Use forward and back arrows the view past or future months. • Selected dates are highlighted in blue Note: Calendar does not allow entry of appointments. Date must be set within system settings CALCULATOR •...
-
Page 10: Radio
RADIO 1. Scanning: Press, hold, and drag the slider to quickly tune the radio. 2. Current Station: The currently selected station will be displayed in the center. Press the forward and back arrows to change the current station. 3. Favorite Stations: Press and hold one of the six preset slots to set and save a selection for later. -
Page 11: Third Party Apps
THIRD PARTY APPS For the detailed operation instruction for a certain 3rd party App, such as Google map, Youtube etc., please contact your 3rd party App provider for further service. Thank you. TROUBLE SHOOTING Q: Unit doesn’t power up A: Use a multi-meter to check for 12v+ to red and yellow wires. Check for proper Ground on the Black wire. Q: My video does not play A: Attach “PARK”... - Page 12 Q: My Map card no longer loads (COCKPIT ERROR DISPLAYED) A: This is caused by bug in map software. Please contact Tech Support: Pyle, go to www.PyleUSA.com the “contact us” page. A: You may be able to ix the software on your own - Insert GPS card into computer - Open text ile under Primo\save\pro iles\01\system.ini...
-
Page 13: Wiring
WIRING BACK PANEL WIFI ANTENNA 3G/USB/DVR 3G/USB/DVR 3G/USB/DVR GPS ANT BT/MIC SUBWOOFER OUTPUT RADIO ANT A. Video Input B. Video Output 1 C. Video Output 2 D. Left Audio Input E. Front Left Audio Output F. Rear Left Audio Output G. - Page 14 WIRING COLOR WIRING GROUND BACK UP CAMERA Radio Antenna Radio antenna receptacle Subwoofer Output Pre amp subwoofer output (5V) Audio / Video Input Auxiliary input for external hardware Audio / Video Output 1 Connect to headrest display (Optional) Audio / Video Output 2 Connect to headrest display (Optional) SW KEY Steering wheel control Key 1 interface wire...
- Page 15 BLUETOOTH Bluetooth app allows Bluetooth pairing with compatible devices for making calls and music playback. To pair your phone, ensure Bluetooth is enabled in your phone’s system settings and that you are disconnected from all other devices. In the Bluetooth app of your radio, press the “Gear” icon in the left column to access Bluetooth settings. Next, press the “Magnifying glass”...
- Page 16 HOW TO ACCESS INTERNET How to access internet? You have three ways to access internet. 1. Use a 3G dongle Insert USB type 3G dongle to one of the rear USB port, wait for few seconds, then 3G signal icon will be shown on status bar, and you can access internet now.
- Page 17 Output Setup Auto Segmentation: The video le recorded should not be too large, otherwise it will increase memory consumption when opening le which may cause playback failure. When you choose high-resolution, the video le recorded will be larger, so it may be appropriate to shorten the split time. Auto Delete Old Video: When there is not enough free space in the storage, it will automatically delete the oldest recorded video to clear space for newly recorded video.
-
Page 18: Installation
INSTALLATION /MUTE HOME NAVI VOL- VOL+ www.PyleUSA.com... - Page 19 REAR VIEW BACKUP CAMERA INSTALLATION: Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. The installation instructions do not apply to all types of vehicles, and are written as guidelines to assist in installing the system. Please consult an experienced technician if you are not comfortable installing the product.
- Page 20 System Installation and Wiring Note: Camera System installation on diesel vehicles may require a slightly di erent wiring install. Caution: Connecting to other types of electrical systems will cause damage to your vehicle. Please contact the manufacturer if you are unaware of the system type in your vehicle. Refer to the model's power requirements prior to connection and installation.
- Page 21 Angle Adjustable Camera Lens • Located on the camera housing are 2 screws which lock the camera lens angle in position. • The screws may be loosened to allow camera lens angle adjustment • Loosen the screws, adjust the camera lens into the desired angle. then tighten the screws securely. •...
-
Page 22: Phone Link Software
PHONE LINK SOFTWARE This phone link software is developed by a 3rd party Apps developer, which we provided to our valued customers free of charge. As mobile phones manufacturers are keeping on upgrading their system, this device may not be compatible with their upgraded operating system, we will not be responsible for these incompatibility. - Page 23 3.3.Transmit mobile phone sound to vehicle navigator Transmit the sound to the vehicle navigator to facilitate receiving and making a call. At the same time, the mobile phone audio can be transmitted to the vehicle terminal through A2DP protocol, and is played by the car loudspeaker.
