PLDVD198
OWNER'S MANUAL
Mobile Video System
Digital Audio Out-Coaxial
PLL Synthesizer Stereo Radio
DVD Player
Automatic Memory Storing
Full Detachable Panel
Preset Equalization
Multi-subtitle Languages Function
Multi-audio Languages Function
Multi-angle Function
Parental Control
Remote Control
www.pyleaudio.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLDVD198 and is the answer not in the manual?

Questions and answers

Related Manuals for Pyle PLDVD198

Summary of Contents for Pyle PLDVD198

  • Page 1 PLDVD198 OWNER'S MANUAL Mobile Video System Digital Audio Out-Coaxial PLL Synthesizer Stereo Radio DVD Player Automatic Memory Storing Full Detachable Panel Preset Equalization Multi-subtitle Languages Function Multi-audio Languages Function Multi-angle Function Parental Control Remote Control www.pyleaudio.com...
  • Page 2 FEATURES Compatible with NTSC DVD (Video CD) This player can play discs recorded in either PAL or NTSC format. A single LSI chip now integrates all major DVD playback circuit functions including MPEG2 decoder, video D/A converter, and audio decoders. L/R stereo analog audio outputs for connection to existing head unit aux inputs.

  • Page 3: Table Of Contents

    CONTENTS Safety Information ... 4 Disc Notes ... 5 Installation ...6 Using the Detachable Front Panel Wiring Connection ...10 20 Pin Socket Connection ... 1 0 Location and Function of Keys ... 11 The Player ...12 Remote Control Remote Control ...

  • Page 4: Safety Information

    SAFETY INFORMATION CAUTION: MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS MOBILE DVD PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE MOBILE DVD PLAYER CORRECTLY AS INSTRUCTED.

  • Page 5: Disc Notes

    DISC NOTES Disc formats supported by this player 12 cm disc (Single-sided disc only) VIDEO CD 12 cm disc 12 cm disc 12 cm disc Discs which cannot be played with this player DVD-ROM DVD-R/DVD-RAM CD-G Handling and Cleaning Dirt, dust, scratches and warping disc will cause misoperation.

  • Page 6: Installation

    INSTALLATION Notes: Choose the mounting location where the unit will not interfere with the normal driving function of the driver. Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly.
  • Page 7 INSTALLATION Mount the sleeve by inserting the sleeve into the opening of the dashboard and bend open the tabs located around the sleeve with a screwdriver. Not all tabs will be able to make contact, so examine which ones will be most effective. Bending open the appropriate tabs behind the dashboard to secure the sleeve in place.

  • Page 8: Din Rear-Mount (Method B)

    INSTALLATION DIN REAR-MOUNT (Method B) If your vehicle is a Nissan, Toyota, follow these mounting instructions. Use the screw holes marked T (Toyota), N (Nissan) located on both sides of the unit to fasten the unit to the factory radio mounting brackets supplied with your vehicle.

  • Page 9: Using The Detachable Front Panel

    USING THE DETACHABLE FRONT PANEL REMOVING THE FRONT PANEL 1. Press the release button on the front panel and pull off the front panel. Release Button Front Panel 2. Keep front panel into the case. INSTALLING THE FRONT PANEL To install the front panel, insert the panel into the housing and make sure the panel is properly installed.

  • Page 10: Wiring Connection

    WIRING CONNECTION 20 PIN SOCKET CONNECTION ANTENNA CONNECTOR ANTENNA SOCKET(OPTIONAL) FRONT Lch SPEAKER WHITE/BLACK REAR Lch SPEAKER GREEN/BLACK AUDIO R IN (RED) AUDIO L IN (WHITE) VIDEO IN ( ( YELLOW) ) AV IN CABLE(BLACK) VIDEO OUT 1(YELLOW) VIDEO OUT 2 (YELLOW) DIGITAL AUDIO (ORANGE) AV OUT CABLE(GREY) FUSE...

  • Page 11: Location And Function Of Keys

    LOCATION AND FUNCTION OF KEYS THE PLAYER 1. PWR (power button) 2. LOC 3. MUT 5. Disc Slot 6. MODE 8. Liquid Crystal Display 9. L/R (ST) 10. SEL 11. VOL 12. VOL When remove the front panel: 25. LED 13.

  • Page 12: Remote Control

    LOCATION AND FUNCTION OF KEYS REMOTE CONTROL...
  • Page 13 LOCATION AND FUNCTION OF KEYS 1. POWER Press POWER to turn the unit ON or OFF. 2. MUTE Press to mute the sound. 3. SUB-T Changing of the SUBTITLE language on multi-subtitle language DVD disc. 4. ANGLE Changing of the view angle on multi-angle DVD disc. 5.

  • Page 14: Remote Control

    REMOTE CONTROL Preparing the Remote Control Inserting the Batteries 1. Open the battery compartment cover. 2. Insert the new battery. Make sure that the positive and negative terminals of the battery are oriented as indicated. 3. Close the cover. Battery: a button cell lithium battery (CR2025 3V) Using the Remote Control Point the remote control towards the...

  • Page 15: Loading/Ejecting A Disc

    LOADING/EJECTING A DISC Loading a Disc When all connections have completed, you can load a disc as follows: 1. Turn the ignition on to the accessory position. 2. Press the PWR button (1) on the front panel or POWER button on the remote controlto turn on the unit.

  • Page 16: Operation

    OPERATION BASIC OPERATION SWITCHING ON/OFF THE UNIT Press PWR button on the front panel or POWER button on the remote control to turn on the unit. FACEPLATE RELEASE Press button on the front panel to detach the removable faceplate. SOUND ADJUSTMENT Press SEL button on the front panel of the unit or on the remote control to select the desired adjustment mode.

  • Page 17: Radio Operation

    OPERATION - Initial installation of the unit when all wiring is completed. - All the function buttons do not operate. - Error symbol on the display. Note: if press RESET button, the unit can't work yet, please use a cotton swab soaked in isopropyl alcohol to clean the socket on the front panel.

  • Page 18: Disc (Dvd/Vcd/Cd/Mp3) Operation

    OPERATION DISC (DVD/VCD/CD/MP3) OPERATION STOPPING PLAY Briefly press the (Stop) button to stop the unit playback, when button on the front panel or on the remote control is pressed, normal playback will continue. Press (Stop) button twice to stop the playback and go back to initial Track/Chapter.
  • Page 19 OPERATION REPEATING PLAYING A PASSAGE A-B repeat allows a passage to be repeated continuously. Press A-B button on the remote control at the start of the required passage, then press A- B button again at the end of the passage. To revert to normal playing, press A-B button again.
  • Page 20 OPERATION Title Number, Total Title Number, Chapter Number, Total Chapter Number of this Title of the disc currently being played will be shown on the screen, along with the elapsed time. (2) Press DISPLAY for the second time: TITLE REMAIN 01:46:58 (3) Press DISPLAY for the third time: CHAPTER ELAPSED...

  • Page 21: Title Menu Function

    OPERATION (2) Press DISPLAY for the second time: CHAPTER REMAIN 01/18 04:25 (3) Press DISPLAY for the third time: The message on the screen will be cleared. MULTI-AUDIO LANGUAGES FUNCTION For DVD: Press L/R (ST) button on the front panel or ST (AUDIO) button on the remote control during playback.

  • Page 22: Av In Operation

    OPERATION MP3 Disc Play MP3 disc is playing as the format of FOLDER. For example: SMART NAVI ROOT CD01 MP3 001 PLUMT MP3 002 RZID CD02 CD03 MP3 003 ASCIS CD04 MP3 004 DCYI CD05 MP3 005 BFZ PLAY MODE DISC In stop mode, use / , on the...

  • Page 23: Setup

    SETUP INITIAL SETUP SETUP MENU --- MAIN PAGE GENERAL SETUP AUDIO SETUP PREFERENCES EXIT SETUP 1. Press SETUP on the remote control or on the DVD unit in the stop mode. (Press the stop button twice to ensure that the player is in STOP mode.) 2.

  • Page 24: General Page

    SETUP -- GENERAL PAGE -- TV DISPLAY PIC MODE AUTO ANGLE MARK HI-RES OSD LANG N-FLICKER CAPTIONS SCR SAVER MAIN PAGE PIC mode setup Select AUTO, the player PIC mode will depend on DVD disc. Select HI-RES format for best image resolution.

  • Page 25: Audio Setup

    SETUP -- GENERAL PAGE -- TY DISPLAY PIC MODE ANGLE MARK OSD LANG CAPTIONS SCR SAVER MAIN PAGE SCR SAVER setup Select the SCR SAVER ON/OFF. AUDIO SETUP -- AUDIO SETUP -- SPDIF OP MODE DUAL MONO DYNAMIC PRO LOGIC LPCM OUTPUT MAIN PAGE SPDIF...

  • Page 26: Preferences Setup

    SETUP -- AUDIO SETUP -- SPDIF OP MODE FULL DUAL MONO DYNAMIC PRO LOGIC LPCM OUTPUT MAIN PAGE Dynamic range Control Select DYNAMIC and adjust the dynamic range of a Dolby Digital encoded program. There are 8 steps between full compression and off compression.

  • Page 27: Preferences Page

    SETUP --PREFERENCES PAGE-- TV TYPE AUDIO ENGLISH SUBTITLE FRENCH DISC MENU SPANISH PARENTAL CHINESE PASSWORD JAPANESE DEFAULTS GERMAN MAIN PAGE AUDIO language setup Select the preferred AUDIO soundtrack by using the cursor buttons. --PREFERENCES PAGE-- TV TYPE AUDIO SUBTITLE ENGLISH DISC MENU FRENCH PARENTAL...

  • Page 28: Defaults Table

    SETUP --PREFERENCES PAGE-- TV TYPE AUDIO SUBTITLE DISC MENU PARENTAL PASSWORD CHANGE DEFAULTS MAIN PAGE PASSWORD Select CHANGE and press OK button. Type the old password (The initial factory code is 3308) and key in 4 characters password now you want to use, and retype again to confirm key in correctly.

  • Page 29: Trouble Shooting

    TROUBLE SHOOTING If it appears that your DVD unit is faulty, first consult this checklist. It may be that something simple has been overlooked. Under no circumstances should you try to repair the player yourself, as this will invalidate the warranty. Only qualified service personnel can remove the cover or service this player.

  • Page 30: Specifications

    SPECIFICATIONS GENERAL Power Supply Requirements Chassis Dimensions Tone Controls Bass (at 100 Hz) Treble (at 10 kHz) Maximum Output Power Current Drain CD PLAYER Signal to Noise Ratio Channel Separation Frequency Response RADIO Frequency Coverage 87.5 to 107.9 MHz 10.7 MHz Sensitivity (S/N=30dB) Stereo Separation >25dB...
  • Page 31 SPECIFICATIONS Supply voltage: 12V DC (11V-15V), test voltage 14.4V, negative ground Current consumption: Less than 2A Signal system: Compositive video 1.0Vp-p 75 Discs played: (1) DVD-VIDEO disc 5” (12 cm) single-sided, single-layer 5” (12 cm) single-sided, double-layer (2) Compact disc (CD-DA/CD-R/CD-RW/MP3) (3) 5”...
  • Page 32 www.pyleaudio.com 88-V1005-01...
