- Page 1 FA902900TX-Ebony Stain Stockton Media Fireplace For assistance with assembly, contact: Southern Enterprises Inc. Assembly Instructions Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
- Page 2 Stockton Media Fireplace Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing.
- Page 3 Quantity Quantity of 1 of 2 Top Panel Middle Side Panel Quantity Quantity of 1 of 1 Middle Shelf Panel Bottom Panel Quantity Quantity of 1 of 1 Left Side Panel Right Side Panel Quantity Quantity of 2 of 2 Side Shelf Panel Left Leg Quantity...
- Page 4 Stockton Media Fireplace Assembly Instructions Insert 4pcs cam locks (C) into holes on side panels (5) and (6). Screw 4pcs cam bolts (A) into holes on middle shelf panel (3). Attach side panels (5) and (6) to middle shelf panel (3) by inserting wood dowels (B) and cam bolts (A) into corresponding holes until middle shelf panel (3) and side panels (5)
- Page 5 Stockton Media Fireplace Assembly Instructions Insert 4 pcs cam locks (C) into holes on side shelf panels (7). Screw 4pcs cam bolts (A) into holes on assembled unit. Attach side shelf panels (7) to assembled unit by inserting wood dowels (B) and cam bolts (A) into corresponding holes until side shelf panels (7) and assembled unit meet .
- Page 6 Stockton Media Fireplace Assembly Instructions Attach legs (8) and (9) to assembled unit by inserting the bolts on the legs into corresponding holes on the corner of middle shelf panel (3), side panels (7), and bottom panel (4). Use half nuts (E) and hex nuts (F) to connect the bolts (D) on legs.
- Page 7 Stockton Media Fireplace Assembly Instructions Insert 4 pcs cam locks (C) into holes on assembled unit. Screw 4pcs cam bolts (A) into holes on top panel (1). Attach top panel (1) to assembled unit by inserting wood dowels (B) and cam bolts (A) into corresponding holes until top panel (1) and assembled unit meet.
- Page 8 Stockton Media Fireplace Assembly Instructions Use screws (I) to connect wood holder (11) to bottom panel. Tighten screws (I) with Phillips screwdriver. Figure 9 Use short screws to connect brackets to the underside of the top panel (1) as shown. Tighten screws with phillips screwdriver.
-
Page 9: Parts Replacement Form
Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product. - Page 10 DO NOT EXCEED RECOMMENDED LOAD. Use with products heavier than the maximum sizes and weights indicated may result in instability causing possible injury. This unit contains a permanent warning sticker located on back panel. Model: FA902900TX Stockton Media Fireplace Southern Enterprises, Inc...
