- Page 1 FA933800TX- Hadley Media Fireplace - Walnut/Espresso For assistance with assembly, contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com...
-
Page 2: Parts List
Hadley Media Fireplace Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. - Page 3 Quantity Of 1 Anti-Tipping Hardware Quantity Quantity of 1 of 2 Top Panel Middle Side Panel Quantity Quantity of 1 of 1 Middle Shelf Panel Left Side Panel Quantity Quantity of 1 of 1 Middle Divided Panel Right Side Panel Quantity Quantity of 1...
- Page 4 Quantity Quantity of 2 of 1 Adjustable Foot Quantity Quantity of 1 of 1 Back Panel Adjustable Shelf Panel Quantity Quantity of 1 of 1 Door Panel Cross Rail Quantity of 1 Wood Holder Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth. Periodically apply furniture wax to renew Call Customer Service at 1-800-633-5096 for assistance, the finish.
- Page 5 Hadley Media Fireplace Assembly Instructions Insert 8pcs wood dowels (B) into holes on middle side panels (2). Slip one end of middle side panels (2) into holes on bottom panel(1). Then, attach middle shelf panel (3) to middle side panels (2) as shown. Use 4pcs long bolts (E) through lock washers (F) and flat washers (G) to connect middle shelf panel (3)
- Page 6 Hadley Media Fireplace Assembly Instructions Insert 6pcs cam locks (C) into holes on assembled unit from figure 2 and left side panel (4). Screw 6pcs cam bolts (A) into holes on assembled unit from figure 1. Attach assembled unit from figure 2 and left side panel (4) to assembled unit from figure 1 by inserting wood dowels (B) and cam bolts (A) into...
- Page 7 Hadley Media Fireplace Assembly Instructions Insert 2pcs cam locks (C) into holes on cross bar (8). Screw 2pcs cam bolts (A) into holes on legs (9). Attach legs (9) to cross bar (8) by inserting 4pcs wood dowels (B) and 2pcs cam bolts (A) into corresponding holes until cross bar (8) and legs (9) meet.
- Page 8 Hadley Media Fireplace Assembly Instructions Use screws (I) to connect back panel (11) to the back of the unit as shown. Tighten by rotating screws (I) clock wise with Phillips screwdriver. Figure 7 Use screws (L) to connect hinges (K) to door panel (13).
- Page 9 Hadley Media Fireplace Assembly Instructions Use screws (L) to connect door panel (13) to the right side of the unit as shown. Tighten by rotating screws (L) clockwise with phillips screwdriver. Insert shelf pins (J) into holes on the unit keeping all shelf pins parallel to each other.
- Page 10 HADLEY MEDIA FIREPLACE Assembly Instructions Use screws (N) to connect wood holder (15) to bottom panel. Tighten screws (N) with Phillips screwdriver. Figure 11 Use short screw to connect brackets to the underside of the top panel (1) as shown.Tighten screws with phillips screwdriver.
-
Page 11: Parts Replacement Form
Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product. - Page 12 CAUTION The top shelf is intended for a flat screen television with a maximum overall width of 40” and supports up to 85 lb. should not be loaded with more than 30 lb. Open center shelf Each Enclosed side shelf should not be loaded with more than 20 lb.
