Summary of Contents for SEI RIALTO FA351000TX
- Page 1 FA351000TX RIALTO MIRRORED MANTEL FAÇADE -WALNUT For assistance with assembly contact: Southern Enterprises Inc. ASSEMBLY INSTRUCTION Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
- Page 2 RIALTO MIRRORED MANTEL FAÇADE FA352000TX Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below.
- Page 3 RIALTO MIRRORED MANTEL FAÇADE FA352000TX Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below.
- Page 4 RIALTO MIRRORED MANTEL FAÇADE Assembly Instructions USE CAM BOLTS(A) & WOOD DOWELS (B) TO CONNECT UPPER FRONT PANEL(4) & RIGHT SIDE PANEL(2) & LEFT SIDE PANEL(3),INSERT CAM LOCKS(C) INTO HOLES AS SHOWN IN FIGURE 1 WITH SLOTS FOR SCREWDRIVER FACING OUTWARD,ROTATE CAM LOCKS(C) CLOCKWISE TO SECURE CAM BOLTS(A) Figure 1...
- Page 5 RIALTO MIRRORED MANTEL FAÇADE Assembly Instructions INSERT THE WOOD DOWELS (L) INTO THE CORRESPONDING HOLES.USE FLAT HEAD SCREW (F) CONNECT MIRROR (6) & FINISHED PART IN FIGURE 2 TOGETHER. Figure 3 ONE HOOK MUST BE ATTACHED DIRECTLY INTO A WALL STUD. NO ANCHORS NEEDED WHEN ATTACHING TO A WALL STUD.
- Page 6 Please contact the retailer that you purchased from for returns. We'd love to hear from you! Email us photos of our products in your home at sei@seidal.com and we might feature it on our site or use it to model one of our inspirational photos.
