  • Page 4 1.Insert cam locks(C) into predrilled holes on 1pc shelf panel(7).Screw cam bolt(A) into predrilled holes on side panel(2R) & middle vertical panel(3R). Attach side panel(2R)& middle vertical panel(3R) to 1pc shelf panel(7) by slipping wood dowel(B) & cam bolt(A) into corresponding predrilled holes until side panel(2R)&...
  • Page 5 3.Insert cam locks(C) into predrilled holes on side panel(2R) & middle vertical panel(3R).Screw cam bolt(A) into predrilled holes on right front panels (5). Attach right front panels (5) to panel(2R) & middle vertical panel(3R) by slipping wood dowel(B) & cam bolt(A) into corresponding predrilled holes until right front panels (5) &...
  • Page 6 5.Insert cam locks(C) into predrilled holes on assembled unit in the step 4.Screw cam bolt(A) into predrilled holes on top panel (1). Attach top panel (1) to assembled unit in the step 4 by slipping wood dowel(B) & cam bolt(A) into corresponding predrilled holes until top panel (1) &...
  • Page 7 7.Insert firebox(13) to the related place of assembled unit. 8.Attached wood holder (11) by inserting flat head screw(F) into corresponding predrilled holes and tightening with Phillips screwdriver(not included).
  • Page 8 9.Insert shelf bracket (D) into corresponding holes,then place adjustable shelf panel (8) on top of shelf bracket (D) . 10. Now your new fireplace is ready to use.
  • Page 9: Parts Replacement Form

    Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product .
  • Page 10 CAUTION The top shelf is intended for a flat screen television with a maximum overall width of 38” and supports up to 65lb. Each center shelf should not be loaded with more than 20 lb. DO NOT EXCEED RECOMMENDED LOAD. Use with products heavier than the maximum sizes and weights indicated may result in instability causing possible injury.

This manual is also suitable for:

Glazed pine fa938700txMahogany fa938800tx
