Regin Corrigo E Manual

• Pre-programmed with all applications and languages
• Ventilation, heating or boiler control
• Model for expansion units
Corrigo E is a range of digital controllers for ventilation,
heating or boiler control. The controllers can be used
stand-alone or as part of a network.
Corrigo E is easy to install and adjust according to your
needs. The controller fits on a standard DIN rail or into a
standard housing.
Corrigo E is available with or without display. Models
without display can be mounted in a cabinet and be
controlled via the external display unit E-DSP, which
functions as a remote control.
Corrigo E - The easy way to perfect control
Corrigo E makes every step from installation to operation
and maintenance easier than ever before. Just connect the
controller, adjust the pre-installed applications if needed
and start up.
The model program has a logical order, which is helpful
when you choose a model for you application. It will also
be easier to get the right functionality at the right price.
Communication
Corrigo E is easy to integrate with existing products. All
models have a port for communication with a PC. Other
standards are available. Read more in the section Corrigo
E with communication on page 3.
Model with web server and TCP/IP
Corrigo E for ventilation and heating applications is also
available in a web version with integrated web server
and TCP/IP communication. Read more about the
possibilities in the section Corrigo E with communication
on page 3.
Android application, Regin Building Access
Web models from version 3.0-1-06 have an integrated
android application for control from e.g. a mobile phone.
The application can be used for ventilation and heating.
Corrigo E
Corrigo E
Version 3.1 (ventilation), 3.1 (heating),
1.1 (boiler).
Controllers for heating, boiler and ventilation
applications in buildings.
• Model with integrated web server
• Different communication possibilities
• Android application for mobile control
Model for expansion units (ventilation and heating)
Corrigo E models from version 3.0 and up are available
with two communication ports. Port 1 is used in the same
way as before, i.e. for connection to SCADA systems and
E tool. Port 2 is used for expansion units. Read more in
the section Corrigo E with communication on page 3.
Applications
• Ventilation control
For control of air handling units with temperature
control (up to 4 sequences), 1- or 2-speed operation,
or alternatively, pressure or air flow control of supply
air fan and extract air fan, humidity control and other
functions within ventilation.
• Heating control
For control of up to three heating systems and one
or two hot water circuits. Pump control, pressure
control of pump, hot water preparation, inputs for
water and energy meter.
• Boiler control
For control of boilers with up to four boilers in
sequence, where each boiler can have single or
double burners. Also for control of up to three
outdoor temperature controlled heating systems
and one domestic hot water system, with the same
functions as for application heating above.
E tool
E tool is a PC-based software which makes it possible
to configure and supervise an installation via a graphical
interface. Read more in the section To use Corrigo E on
page 2.
Display
The display is backlit and has 4 rows of 20 characters. The
illumination is normally off, but is activated as soon as a
button is pressed. It is turned off after a certain period of
inactivity.
revision
02 2013
