Enterprise Mobility

PM66

User Manual

For Android 6.0.1

Table of Contents

Need help?

Do you have a question about the PM66 and is the answer not in the manual?

Questions and answers

Summary of Contents for Point Mobile PM66

Page 2: User Manual
Make sure to use only the power adapter (5V 2A Output AC/DC) that came with PM66. In case your phone does not work as expected, you are strongly recommended to restart it by pressing and holding the power button for at least 12 seconds until the startup screen appears.
Page 3 PM66 Android 6.0.1 User Manual Table of Contents User Manual ..................................1 Table of Contents ................................. 2 Getting Started ..................................3 Major Parts ..................................3 Accessary ..................................5 Setup PM66 ..................................6 Charge PM66 ..................................9 Turn On/Off PM66 ................................10 Hot swap the battery ..............................
Page 4: Getting Started
PM66 Android 6.0.1 User Manual Getting Started Major Parts Major Parts Getting Started 1. Barcode Scanner 2. Speaker 3. Touch Screen 4. Pogo pin connector 5. micro USB ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 5 PM66 Android 6.0.1 User Manual Getting Started Major Parts Getting Started 1. Volume Key 2. Scanner Trigger 3. Flash Light 4. Camera 5. Battery Cover Lock 6. 3.5mm Audio Jack 7. Power Key 8. Scan Trigger Key ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 6: Accessary
PM66 Android 6.0.1 User Manual Getting Started Acc essar y Accessary Getting Started AC/DC adapter Plug (US/ EU/ UK) LCD protection film Li-ion battery ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 7: Setup Pm66
PM66 Android 6.0.1 User Manual Getting Started Setup PM66 Setup PM66 Getting Started Remove the Battery Cover 1. Press “Battery Cover Lock” button 2. Pull up the Battery Cover from bottom side area Insert SIM card 1. Insert the SIM card into the slot. (Gold plate should face down) 2.
Page 8 PM66 Android 6.0.1 User Manual Getting ` Star ted Setup PM66 Getting Started Note: Your device only supports SIM cards. Do not attempt to insert other SIM types such as “Micro” and “Nano” SIM card, this may cause damage to your device. If you have to use different SIM card types, please use “SIM adaptor”.
Page 9 PM66 Android 6.0.1 User Manual Setup PM66 Getting Started Insert the Battery Insert “Battery” from top area first and then put in bottom area. Make sure battery contact “Battery Connector” Close the Battery Cover Insert “Battery Cover” from the top area first and then put in bottom area. Press battery cover with both hand firmly ©2006 –...
Page 10: Charge Pm66
Charging time Standard Battery : About 6hours Note: Always use an original charger and cable from the Point Mobile. Other chargers and cables may damage PM66. In addition, make sure connector, charger, cables are not wet. ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 11: Turn On/Off Pm66
Turn On 1. Press and hold down the “Power Key” for a few seconds. 2. When PM66 enter to the boot mode, it will display “SMART BEYOND RUGGED” logo with short vibration 3. Release the “Power Key” and wait until PM66 finish booting Note: If you cannot turn on your PM66, try below steps To turn on PM66, battery needs to be charged certain level.
Page 12: Hot Swap The Battery
Hot s wap the batter y Hot swap the battery Getting Started When battery level is low, you can replace the battery without turning off and on PM66. Remove the Battery and replace to another one. Make sure the battery cover closed firmly.
Page 13: Learning The Basics
Adjusts the media volume. In camera preview Take the photo by pressing Volume Up or Down key. Scanner Triggers When “Scan Wedge” mode is activated By pressing, PM66 scan the barcode. ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 14 PM66 Android 6.0.1 User Manual Learni ng the basics Using a keypad Learning the basics Front panel (Touch Key) Recent Apps key Press to see recently used apps. Home key From any apps or screens, press to return to the Home screen.
Page 15: Use A Touch Screen
PM66 Android 6.0.1 User Manual Learni ng the basics Use a touch scr een Use a touch screen Learning the basics Touch One-finger press Double touch One-finger press, lift, one-finger press, lift for “Zoom in” Long press One-finger press, wait, lift for “Select an item”...
Page 16 Vertical or horizontal swipe in a single direction Pinch Open & Close Two-finger press, move outwards and inwords, lift for “Zoom in and out” Rotate When PM66 is turning sideways, screen orientation is changing ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 17: Home Screen, Apps And Widget
PM66 Android 6.0.1 User Manual Learni ng the basics Home Scr een, Apps and Widg et Home Screen, Apps and Widget Learning the basics Status Bar Status / Notification Drag down to open the “Quick Setting Panel” Search Bar Touch 1 to search by text...
Page 18 PM66 Android 6.0.1 User Manual Learni ng the basics Home Screen, Apps and Widget Learning the basics Remove the app icon from home screen Long press the app icon and then drag it to the “Remove” area and then release Create “App Folder”...
Page 19 PM66 Android 6.0.1 User Manual Home Screen, Apps and Widget Learning the basics Notification panel When there are notifications from the Android (system) or the App, you can check details by drag down the “Status Bar”. Quick setting panel You can access “Quick setting panel” by drag down the “Notification panel”.
Page 20 PM66 Android 6.0.1 User Manual Learni ng the basics Home Screen, Apps and Widget Learning the basics By touching the “App drawer” icon, you can enter to the “Apps” and “Widgets” All installed apps are listed in the “Apps” tab, alphabetically Tap app icon to run.
Page 21: Status & Notifications Icons
PM66 Android 6.0.1 User Manual Learni ng the basics Status & Notific ations Ic ons Status & Notifications Icons Learning the basics Status icons GPRS connected GPRS in use EDGE connected EDGE in use 3G connected 3G in use 4G connected...
Page 22 PM66 Android 6.0.1 User Manual Learni ng the basics Status & Notifications Icons Learning the basics Notification icons Missed call New SMS or MMS message New Email Connected to VPN network Upcoming event Screenshot captured SD card removed, Preparing SD card...
Page 23: Make A Call
PM66 Android 6.0.1 User Manual Learni ng the basics Make a call Make a call Learning the basics Touch icon in the Favorite tray apps Slide to access the “FAVORITE”, “RECENTS” and “CONTACTS”. To make a call from recent call list or missed call, select “RECENTS”...
Page 25: Add To A Contact
PM66 Android 6.0.1 User Manual Learni ng the basics Add to a contact Add to a contact Learning the basics “App Drawer” icon and then Touch icon CREATE A NEW CONTACT You can manually create the new contact SIGN IN TO AN ACCOUNT You can sync with your contacts in the Google account.
Page 26: Send A Message
PM66 Android 6.0.1 User Manual Learni ng the basics Send a mes sag e Send a message Learning the basics Touch icon in the Favorite tray apps Touch to use a dialer Touch to type a name, phone number or email Suggest contact display here.
Page 27 PM66 Android 6.0.1 User Manual Learni ng the basics Send a message Learning the basics Your message display here Touch to send the composed message You can attach photo, saved picture, voice or location Note: You may allow granting “Message App” access specific app or service.
Page 28: Connect To Your Wi-Fi Network
PM66 Android 6.0.1 User Manual Learni ng the basics Connect to your Wi-Fi networ k Connect to your Wi-Fi network Learning the basics “App Drawer” - “Settings” and then Touch “WLAN” Touch to turn On / Off the W-Fi You can see nearby Wi-Fi network. Each AP’s SSID information listed by signal strength Icon means: Open Wi-Fi network.
Page 29 Connect to your Wi-Fi network Learning the basics Touch SSID, which you want to connect. To connect to secured network, enter the password Your PM66 is obtaining the IP address from selected AP ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 30: Scanner Settings
PM66 Android 6.0.1 User Manual Scanner Setti ngs Use a Scanner Use a Scanner Scanner Settings Default setting of Scanner is “Off” To use the Scanner, EmKit and then “ScanSetting” Touch “App Drawer” - “Settings” and Touch then “ScanSettings” Touch to turn on the Scanner...
Page 31 PM66 Android 6.0.1 User Manual Scanner Setti ngs Use a Scanner Scanner Settings Now you can see “Scanner” icon in the “Status Bar” Note: When “Scanner” turned on, you can scan the barcode with “ScanDemo” in the EmKit ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 32 PM66 Android 6.0.1 User Manual Scanner Setti ngs Use a Scanner Scanner Settings Scanner setting details Scanner setting consist with “Basic”, “Options”, “Notification”, “Wedge”, “Symbologies”, and “About” In the “Basic”, you can set “Scanning” option and “Wedge” mode option In the “Scanning menu”, you can change Scanner’s trigger time out and set “Auto scan”...
Page 33 PM66 Android 6.0.1 User Manual Scanner Setti ngs Use a Scanner Scanner Settings In the “Options”, you can enable / disable the “Center Window”, set “Decode mode”, “Power save mode” and enable / disable “Aimer” & “Illumination” In the “Notification”, you can set notification option. You can...
Page 34 PM66 Android 6.0.1 User Manual Scanner Setti ngs Use a Scanner Scanner Settings In the “Wedge”, you can enable / disable “Barcode ID” and “Aim ID”, set “Group separator”, “Prefix” & “Suffix” and “Character set” ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 35 PM66 Android 6.0.1 User Manual Scanner Setti ngs Use a Scanner Scanner Settings In the “Symbologies”, you can enable / disable specific barcode. By touching each “Symbology” name, you can set detail option. ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 36 PM66 Android 6.0.1 User Manual Scanner Setti ngs Use a Scanner Scanner Settings In the ‘About’, you can check your Scanner’s information and restore Scanner’s settings to default ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 37: Scan A Barcode
PM66 Android 6.0.1 User Manual Scan a Barc ode Scan a Barcode Scanner Settings Example of good Barcode reading Idle barcode scan Please aim the middle of barcode Even you aim the barcode slightly upper or down area or angle is tilted, you can read the barcode...
Page 38 PM66 Android 6.0.1 User Manual Scan a Barc ode Scan a Barcode Scanner Settings Example of bad Barcode reading If you aim the barcode wrong direction or tilt too much, you can’t read the barcode If you aim part of Barcode or aim two barcode together, you can’t read the barcode...
Page 39: Os Update
PM66 Android 6.0.1 User Manual OS U pdate OS Imag e update from a Storag e OS Image update from a Storage OS Update To update OS image, copy or place OS image file into the root folder of “Internal Storage” or “External Storage”...
Page 40 By touching the “CONTINUE” button, your PM66 start to update the OS image. During this time, you cannot use your PM66. Please save the data before start, the OS update process. ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 41: Os Image Update From The Fota
PM66 Android 6.0.1 User Manual OS U pdate OS Imag e update from the FOT A OS Image update from the FOTA OS Update icon for the advanced option Touch “FOTA Client” ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 42 OS U pdate OS Image update from the FOTA OS Update PM66 will compare the OS image between FOTA server and current OS image. If there is newer OS image in the FOTA server, FOTA server will suggest downloading. Touch “OK” to start download the image in the FOTA server...
Page 43: Factory Data Reset
Factor y data res et from Setti ngs Factory data reset from Settings Factory data reset When your PM66 system is unstable and abnormal behavior occur but could not recover by rebooting, you may need to “Factory data reset” your PM66 “App Drawer”...
Page 44 PM66 Android 6.0.1 User Manual Factory data reset from Settings Factory data reset Please note, all apps and data in the internal storage will be deleted and restored to “Factory default” and this process cannot “Undo” Touch to start “Factory Reset” process Touch to confirm erase of “Apps and Data”...
Page 45: Force Factory Data Reset
Force Factory data reset your PM66 You can perform “force” factory data reset your PM66. When your PM66 turned off, press “Power” + “Volume up” + “Home” button all together. After short vibration from your PM66, you may release the buttons.
Page 46 Factor y data Res et Force Factory data reset Factory data reset Select “Wipe data/factory reset” Select “Yes” to perform the “Factory data reset” After that, your PM66 start wiping the data ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 47 PM66 Android 6.0.1 User Manual Factor y data Res et Force Factory data reset Factory data reset After data wiping, please select “Reboot system now” to finish the “Force Factory data reset” process ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 48: Emkit
Enterprise Mobility Kit – Truly, what Enterprise needs Point Mobile announces new software solution – called “EmKit” is new software solution for enterprise mobility users. Our every Android device shall have EmKit pre-installed and every use can access them for free of charge*.
Page 49: Emkit Secure
EmKit Sec ure EmKit Secure EmKit Power Launcher You can lock your PM66’s “Home Screen” and limit to access “Settings” from “Quick Setting” panel. This function as known as “Kiosk” mode Program Buttons You can assign Hardware buttons function to rich pre- assigned functions.
Page 50: Emkit Remote
PM66 Android 6.0.1 User Manual EmKit Remote EmKit Remote EmKit Airwatch Agent preinstalled. Select option for enrollment process SOTI Mobi Control preinstalled Enter enrollment information for the next process ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 51 PM66 Android 6.0.1 User Manual EmKit Remote EmKit Remote EmKit Teamviewer Quick Support App and Plugin, preinstalled. You may need to purchase “Teamviewer” license during remote access and control ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 52: Emkit Tools
EmKit Tools EmKit Backup & Restore You can create the “Golden sample” and then “Restore” I to other PM66 easily ScanSetting You can set your PM66’s scanner option with intuitive menu ©2006 – 2017 POINTMOBILE Co., Ltd. All rights reserved...
Page 53 PM66 Android 6.0.1 User Manual EmKit Tools EmKit Tools EmKit System information All of SW and HW information available here and can save it to the file. Touch “Save to file” devinfo.html file saved to root folder of the internal storage.
Page 54 Copyright © 2006-2017 Point Mobile Co., Ltd. All rights reserved. Point Mobile Co., Ltd. is the designer and manufacturer of handheld mobiles. Point Mobile Co., Ltd. Logo are registered trademarks and symbols of Point Mobile Co., Ltd. Features and specifications are subject to change without prior notice.
