- Page 1 920i AC/DC Version ® Agricultural Multi-Animal Indicator Operation Manual December 13, 2017 PN 184718...
- Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
- Page 3 5.5 Specifications ..................20 Technical training seminars are available through Rice Lake Weighing Systems.
- Page 4 920i® AC/DC Version for Agricultural Multi-Animal Indicator Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost. Visit www.ricelake.com/webinars Visit our website www.RiceLake.com...
-
Page 5: Introduction
Introduction Introduction The 920i AC/DC Indicator can be installed on most Rice Lake Weighing Systems livestock scales. This system is manufactured with top quality components and is engineered using the latest technology to provide operating features and reliability unmatched for years to come. -
Page 6: Front Panel
920i AC/DC Version Agricultural Multi-Animal Indicator Front Panel Front panel keys and annunciators are described in the following sections. 1/5/2015 10:34 AM Scale #1 Scale -888.8888 Mode Units Shrink Factor: 2% Live Total: 1000 Last Weighment: Current Weighment: Totals: Head Ct: 43... -
Page 7: Softkeys
19,500, they will want to only add 500 worth of animals). Verify Head Count Turns head count verification On/Off. Exit Returns the display to the main screen. Table 1-3. Setup Soft Keys © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 8: Indicator Settings
Time and Date The 920i AC/DC Indicator has a built-in time and date clock that automatically adjusts for leap years. The real time clock will run even if power is removed from the indicator. There is a battery inside the indicator that will keep the clock running continuously while there is no power to the indicator. -
Page 9: Operation
The following sections describe the basic operation of the 920i AC/DC Indicator. IMPORTANT A printer is optional, so all references only apply if there is a printer connected to the 920i AC/DC indicator. Weighing Multiple Animals 1. Press the power switch to turn on the indicator. -
Page 10: Weigh Ticket Print-Out (Optional)
920i AC/DC Version Agricultural Multi-Animal Indicator 2.1.1 Weigh Ticket Print-Out (Optional) Press to obtain the Weigh Ticket for the current batch of animals. Batch Complete 02/04/2016 05:52PM Weight UM Avg Wt ---------------------------------- 7720 7915 8010 ---------------------------------- 23645 311 Gross 23645 311 Net 0.00% Shrink... -
Page 11: Weighing A Single Animal
It will prompt the operator to re-enter the head count value, immediately after the original Head Count value is entered. If the operator enters a different value, the program will store and print the latest value entered. © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 12: Configuration
920i AC/DC Version Agricultural Multi-Animal Indicator Configuration Configuration Mode The setup switch must be pressed to enter the configuration mode. If the indicator has an NTEP seal, it needs to be cut to access the switch. IMPORTANT For continued NTEP certification the indicator must be resealed by an authorized agent. -
Page 13: Database And Stored Workbooks
Table 3-4. Serial Port (PN 129998) for Mobile Scale with Inclinometer Port Type Description Setup Not Used 9600,8,N,2 Flash Drive/Keyboard Not Used 9600,8,N,2 TM295 ticket printer 9600,8,N,2 Table 3-5. Serial Port (PN 132302) for Static Scale without Inclinometer © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 14: Usb Flash Drive
USB Connector Figure 3-2. USB Drive Location 3.3.1 USB Driver Installation Before connecting the 920i AC/DC Indicator to a PC, the appropriate driver must be installed. 1. Open the Rice Lake website at www.ricelake.com 2. Navigate to the 920i USB page. -
Page 15: Usb Softkey
Supports USB 2.0 flash drives formatted to the FAT-32 or FAT-16 file system up to 4 G max Table 3-6. USB Devices Use the following to connect a USB device: 1. Attach the USB device to the proper USB connector on the indicator. USB connections use Port 2 on the 920i. 2. Press the softkey. -
Page 16: Loading Configuration Files And Databases
3.3.6 Loading Configuration Files and Databases Certain files may take extended periods of time to load directly from a PC to the 920i. A flash drive is recommended for fast loading times. When using multiple 920i units, it is recommended to create a folder matching each ones unit ID number. When loading configuration files, the unit will load the file contained in a folder matching its UID# (the default UID# is 1). -
Page 17: Loading Database Files
Enter Saving Configuration Files and Databases Certain files may take extended periods of time to save directly from a PC to the 920i. For fastest save times, using a flash drive is recommended. When saving a configuration file, the indicator will attempt to save to a folder matching its UID number (the IMPORTANT default UID# is 1). -
Page 18: Front Panel Calibration
Millivolts Figure 4-1. WZERO Calibration Display The CALIBR sub-menu (under the SCALES menu) is used to calibrate the 920i AC/DC Indicator. The zero, span and linear calibration point displays provide a set of softkeys used specifically for calibration procedures. Sub-menu... -
Page 19: Appendix
Conn,3 Pos Screw Terminal 71126 Conn, 4 Pos Screw Terminal 75062 Washer, Bonded Sealing SST 77180 Conn, 8 Pos Screw Terminal 94422 Label, Capacity 0.40 x 5.00 Table 5-1. Parts Kit © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 20: Repair Parts
920i AC/DC Version Agricultural Multi-Animal Indicator Repair Parts DC Power Supply AC Power Supply Figure 5-1. 920i AC/DC Animal Weigher Parts Illustration Visit our website www.RiceLake.com... - Page 21 Vent, Breather Sealed Gortex Membrane Black Plastic 88734 Nut, Breather Vent 14862 Screw, Mach 8-32 NCx3/8 Phillips Pan Head 53308 Label,1.25 x 1.25 8000T Table 5-2. 920i AC/DC Animal Weigher Parts © Rice Lake Weighing Systems ● All Rights Reserved...
-
Page 22: Dimensions
920i AC/DC Version Agricultural Multi-Animal Indicator Dimensions 12.50" 10.56" 4.61" 8.51" 10.87" 0.14" 10.80" 5.25" 4X Ø.28" 6.00" 2.40" 0.50" 4.25" Figure 5-2. Indicator Dimensions Visit our website www.RiceLake.com... -
Page 23: Troubleshooting Chart
Check for leaks and reseal The weight reading on the Contact Rice Lake Weighing Systems or a qualified dealer for indicator is unstable A load cell cable may be pinched or damaged support;... -
Page 24: Specifications
920i AC/DC Version Agricultural Multi-Animal Indicator Specifications Power 100 - 240 VAC, Range 90 - 264 VAC 12-24 VDC, Range 9 - 36 VDC Power Consumption 340 mA @ 115 VAC (26W) Excitation Voltage 10 ± VDC, 16 x 350 ohm or 32 x 700 ohm load cells per A/D card... - Page 26 Specifications subject to change without notice. Rice Lake Weighing Systems is an ISO 9001 registered company. 230 W. Coleman St. • Rice Lake, WI 54868 • USA U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe +31 (0)26 472 1319...
