AWID MPR-3014WF-QB Installation & Operation Manual

Sentinel-sense mpr-3014

Advertisement

Quick Links

MPR-3014WF-QB
- 1 -
Doc# 041325
SENTINEL-SENSE MPR-3014
MPR-3014WF-QB
Installation & Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPR-3014WF-QB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AWID MPR-3014WF-QB

  • Page 1 MPR-3014WF-QB - 1 - Doc# 041325 SENTINEL-SENSE MPR-3014 MPR-3014WF-QB Installation & Operation Manual...
  • Page 2 COPYRIGHT ACKNOWLEDGEMENTS The contents of this document are the property of Applied Wireless Identifications Group, Inc. (AWID) and are copyrighted. All rights reserved. Any reproduction, in whole or in part, is strictly prohibited. For additional copies of this document please contact:...
  • Page 3 6 dB are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. 1) AWID, model ANT-915CPD-A; 5.9 dBi circular polarized antenna (Patch). 2) Snyder Antenna Systems, Inc., model ANTUHF-PORT-X; 6.5 dBi Patch Antenna (Sidewinder). Note: to compromise the 6.5 dBi antenna gain, part of the included accessories are 8 ft, 16 ft or 24 ft cable to be applied between the reader and antenna.
  • Page 4 4.1. SET UP .................. 11 YSTEM PERATION 4.1.1. Setting Up MPR-3014WF-QB................11 4.1.2. Running a Custom Software Application or the AWID Demo Program ....11 4.1.3. Operating Modes ....................11 4.2........................11 USERS NOTE ..........11 YSTEM NTEGRATORS AND...
  • Page 5: Introduction

    MPR-3014WF-QB-NA (WinCE, Fixed, Quad-Ant, Mono-static & North America) I/O Interface One unique configuration for the MPR-3014WF-QB readers is the possibility of having RS-232 interface and Ethernet interface simultaneously present at the reader data input ports. To arbitrate possible data collision, MPR-3014 determines that local entry always dominates.
  • Page 6: A Ssignment

    Doc# 041325 1.2. MODEL NUMBER ASSIGNMENT Multi-Antenna Readers: MPR-3014WF-QB-YZ MPR – Multiple-protocol RFID QB – quad-bi-static YZ – Two letter web address for country/regional code EXAMPLES: MPR-3014WF-QB-TW for WinCE, fixed, 4-bistatic ant, Taiwan MPR-3014WF-QB-NA for WinCE, fixed, 4-bistatic ant, North America...
  • Page 7: Table

    Read range ............Depends on type & size of labels used Output power ............1 Watt into 6 dBi antenna Antenna configuration ………………………………..1 to 4 antenna pairs Stationary Reader (MPR-3014WF-QB-NA) Operating temperature range ......... -20° C to +65° C (-4° F to 149° F) Color ............... Black Output data formats..........
  • Page 8: Rs-232

    MPR-3014WF-QB - 8 - Doc# 041325 2.2.1. General Purpose Input/Output Terminal block – MPR-3014WF-QB 4 inputs & 4 outputs (optically isolated) Pin # Function description Pin # Function description Output 1 Input Common Output 2 Input 4 Output 3 Input 3...
  • Page 9: Parts List

    3.2.2. Aiming of Antenna Antenna Pattern for MPR-3014WF-QB MPR-3014WF-QB comes with a set of (up to 4) antenna pairs each circular polarized to ensure reading tag with random orientation. Most circular polarized antenna has a horizontal to vertical differential of up to 3 dB, this will cause the antenna pattern to deviate from a true circle.
  • Page 10 • Antenna pattern measurements represent both horizontal and vertical polarized planes of the read area transmitted by the reader. • In the drawing above, R = approximately 12 feet to 15 feet for MPR-3014WF-QB antenna with Alien free space tags.
  • Page 11: Running A Custom Software Application Or The Awid Demo Program

    4.1.2. Running a Custom Software Application or the AWID Demo Program If AWID Demo Program is not used, it is expected user will launch a Custom Software Application developed using the MPR 3014 Protocol and/or RFID Anywhere API to send to reader the commands as specified.
  • Page 12: Mpr-3014Wf Protocol

    Doc# 041325 O FOR DEMO SOFTWARE USERS If you are using the AWID demonstration software application which is .NET based with easy-to-follow GUI operations, simply fill in the IP address of MPR-3014WF-QB installed then click “Connect” should get you started.
