Cartft FLEETPC-ARM-300 Quick Start Manual

Fleet pc series car pc
Hide thumbs Also See for FLEETPC-ARM-300:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Reference Manual
FLEETPC-ARM-300 Quick Start Guide
















































FLEETPC-
ARM-300 Series
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLEETPC-ARM-300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cartft FLEETPC-ARM-300

Summary of Contents for Cartft FLEETPC-ARM-300

  • Page 1 FLEETPC-ARM-300 Quick Start Guide                                   FLEETPC- ARM-300 Series               Quick Start Guide            ...
  • Page 2       This documentation is provided for use with CarTFT.com products. No license to CarTFT.com property right is granted. CarTFT.com assumes no liability, provides no warranty either expressed or implied relating to the usage, or intellectual property right infringement that may result from its use.
  • Page 3 FLEETPC-ARM-300 Quick Start Guide     Table of Contents       PRECAUTIONS ..................5   Safety Precautions.................. 5 Write Prohibited Regions................. 6 Warranty ....................6   OVERVIEW ..................... 7   FLEETPC-ARM-300 Package Contents..............8 FLEETPC-ARM-300 Connectors ................9  ...
  • Page 4 FLEETPC-ARM-300 Quick Start Guide   APPENDIX D: FLEETPC-ARM-300 REMOTE ACCESS ..........38   Access FLEETPC-ARM-300 from a remote Ubuntu PC ..........39   Page 4...
  • Page 5 FLEETPC-ARM-300 Quick Start Guide     Access FLEETPC-ARM-300 from a remote Widows PC ........... 42   Page 5...

  • Page 6: Precautions

    FLEETPC-ARM-300 Quick Start Guide     1 Precautions   Safety Precautions   In order to use this product safely, please take special note of the following precautions.     • Read all product manuals and related documentation before using this product.

  • Page 7: Write Prohibited Regions

    Please note that the other included goods and software are not covered under this warranty. Some knowledge used by CARTFT.COM is provided by third parties, and CARTFT.COM makes no representation or warranty as to the accuracy of such information.

  • Page 8: Overview

      The FLEETPC-ARM-300 is a communication gateway designed for in-vehicle applications or IOT (Internet of Things) applications. The FLEETPC-ARM-300 offers some unique features, including the latest NXP iMX6 (ARM Cortex-A9) quad or dual cores application processor, an LTE modem socket with dual-sim card holder, a ublox GPS receiver, G-sensors, and software controlled power on/off.

  • Page 9: Contents

    FLEETPC-ARM-300 Quick Start Guide       FLEETPC-ARM-300 Package Contents   Standard package content:   Item Notes FLEETPC-ARM-300 device Software and User's Manual     Optional items:   Item Notes +12V Power adapter WiFi Antenna LTE Module GPS Antenna 3G/LTE Antenna...

  • Page 10: 2.2 Fleetpc-Arm-300 Connectors

    USB  LAN1  LAN2  LAN3  LAN4      FLEETPC-ARM-300 Rear Panel     GbE LAN  GPIO GND PWR  HDMI 1.4      USB2.0 Host            For detailed descriptions of the FLEETPC-ARM-300 connector functions, please refer to “FLEETPC-ARM-100 Reference Manual”.   Page 10...

  • Page 11: Basic Installation

        3 FLEETPC-ARM-300 Installation FLEETPC-ARM-300 installation is divided into two portions, basic installation and full installation. You are allowed to perform the following functions after completing basic installation: (1). A PC (or a mobile phone, a tablet with WiFi function) is connected to internet through FLEETPC-ARM-300, and (2).
  • Page 12 Note that 3G or LTE module has to be purchased separately.  One network cable and one PC (Windows), or  One mobile phone/tablet/PC/NB device with WiFi function     Step 1：Inserting sim card into sim card holder SIM1 on FLEETPC-ARM-300 (as shown below):      ...
  • Page 13     If you want to:  Connect FLEETPC-ARM-300 to PC with a network cable, go to Step 3。  Connect FLEETPC-ARM-300 to a mobile phone or tablet with WiFi function, go to Step 4。     Step 3：Connecting one end of a network cable to FLEETPC-ARM-300 LAN port and connecting the other end to PC LAN port.
  • Page 14 FLEETPC-ARM-300 Quick Start Guide       192.168.2.1   DHCP   server   Broadcast IP Internet to phone   Page 14...
  • Page 15     Step 5：If you complete above Step1~Step4 you have completed basic installation on FLEETPC-ARM-300. After entering FLEETPC-ARM-300 device manager on PC (or a phone or a tablet with WiFi function), you may connect to Internet through 3G/LTE modem. For more information about detailed FLEETPC-ARM-300 device manager functions, refer Appendix A.

  • Page 16: Full Installation

    3.3 Remote Access   FLEETPC-ARM-300 is pre-installed a VNC server allowing remote PC (Ubuntu or Windows) to connect to FLEETPC-ARM-300 via LAN port or WiFi. This feature enables remote PCs to monitor and control FLEETPC-ARM-300 without a local LCD display.

  • Page 17: Appendix A: Fleetpc-Arm-300 Device Manager

    Enter username & password (default username: admin, password: 12345678), and press Login to log into the system.     NOTE: The source code of FLEETPC-ARM-300 Device Manager is available for your modification after a purchase. For more information, please contact our sales representative.  ...

  • Page 18: A-1 Gps Function

      GPS function   When GPS antenna is connected and with signal quality, FLEETPC-ARM-300 device manager will display GPS coordinates at 1Hz frequency (refresh coordinates 1 time per second). Note: The map used in device manager is Google Map. The PC (or mobile phone) must be connected to Internet for browser to show GPS coordinates with Google Map.

  • Page 19: A-2 Gpio Function

    GPIO function   GPIO OUT can set HIGH/LOW value and output it to GPO pin on FLEETPC-ARM-300. For example, to enable (turn on) LED 1, select HIGH on device manager and press <Change it> to modify its setting. To disable (turn off) LED 1, select LOW on device manager and press <Change it>...

  • Page 20: A-3 3-Axis G-Sensor Data

    FLEETPC-ARM-300 Quick Start Guide       3-Axis G-sensor Data   This function of 3-axis micro accelerator can measure the changes of x, y, z axes based on the gravity. In case the GPS signal quality is poor and this signal loses GPS navigation ability, the 3-axis information combined with E-compass can be used to establish a complementary azimuth computing system.

  • Page 21: A-4 E-Compass Function

      E-compass function   This page displays FLEETPC-ARM-300 on-board E-compass 3-axis (x, y, z) data. E-compass reports the data by measuring the direction of the Earth's magnetic field. This function can be used to show your present vehicle direction.  ...

  • Page 22: A-5 System Date & Time

    FLEETPC-ARM-300 Quick Start Guide       System Date & Time   This function allows user to set system date and time. In lower portion of user interface, you may use New Date & Time to set system date and time, and click <Change it>...

  • Page 23: A-6 System Monitor

    FLEETPC-ARM-300 Quick Start Guide       System Monitor   This System Monitor function can display current usage of CPU & memory on FLEETPC-ARM-300.      CPU frequency: For showing present processor operating frequency  CPU usage: For showing present processor usage (loading) ...

  • Page 24: A-7 System Parameter Setup

    FLEETPC-ARM-300 Quick Start Guide       System Parameter setup   This function allows you to set some system parameters:      OpenGTS Sever IP: for setting OpenGTS Server TCP/IP information    Unique ID: It sets present device ID. User can setup device ID for this device. Do not use the same ID on multiple devces (ID must be UNIQUE).
  • Page 25 FLEETPC-ARM-300 Quick Start Guide       Page 25...

  • Page 26: A-8 Setting Password

    FLEETPC-ARM-300 Quick Start Guide       Setting Password   Enter your new system login password in New Password field, and click <Change it> to update your old password to the new one.         Page 26...

  • Page 27: A-9 Setting Network

    FLEETPC-ARM-300 Quick Start Guide       Setting Network       Wlan0(WiFi interface) IP setting: for showing and/or setting present TCP/IP, DNS, DHCP for WiFi network. Eth0(Ethernet interface) IP setting: for showing and/or setting present TCP/IP, DNS, DHCP for Ethernet.

  • Page 28: A-10 Setting Wifi

    FLEETPC-ARM-300 Quick Start Guide       A-10 Setting WiFi   WiFi Access Point Parameters Setting:      SSID: for setting WiFi Acess Point name.  Channel: for setting WiFi channel.  Operation Mode: WiFi standard/protocol (b/g/n).  Security Mode: for setting WiFi encryption protocol.

  • Page 29: A-11 Wcdma Monitor

    FLEETPC-ARM-300 Quick Start Guide       A-11 wcdma monitor   This function is to show the status of 3G/LTE modem.      SIM card: for showing a message about whether SIM card is detected.  Mode: for showing SIM card transmission mode for wireless transmission (GSM(2G), WCDMA(3G), LTE) ...

  • Page 30: Appendix B: Opengts Installation (Windows)

    FLEETPC-ARM-300 Quick Start Guide     Appendix B: OpenGTS Installation   (Windows)     OpenGTS is a web server based system created with Java (Open source) so you are required to install a web server (Tomcat). For recording vehicle traveling status, you need to additionally install a MySQL database.
  • Page 31 FLEETPC-ARM-300 Quick Start Guide         Setup folders and system parameters: In Windows desktop, click Start → Programs → Accessories and right click on “Command Line Tool”, and select "Run as Administrator" to run Windows command line tool. In command line tool, enter below commands:...
  • Page 32 FLEETPC-ARM-300 Quick Start Guide     After downloading, run apache-tomcat-7.0.69.exe with default configuration option. Disk D:\ is preferred for target installation. After completing installation, you also need to add system variable. In Windows desktop, click Start → Setup → Console and then click System →...
  • Page 33 FLEETPC-ARM-300 Quick Start Guide     ③ CATALINA_HOME ④ GTS_HOME     To starting your compilation, click windows Start → Programs → Accessories in Windows desktop and click on “Command Prompt” and select "Run as Administrator" to open a command prompt, and type the following commands:  ...
  • Page 34 FLEETPC-ARM-300 Quick Start Guide     and thus a database gts and the following data tables will be created: ① Account - Account owner table ② User - User table ③ UserAcl - User Access-Control-List table ④ Device - Device information table ⑤...
  • Page 35 FLEETPC-ARM-300 Quick Start Guide     and in Passward field, enter yaur passward (Accaunt and Passward are created by executing the cammand bin\admin.bat Accaunt -accaunt:sysadmin -pass:passward -create).   Page 35...

  • Page 36: Appendix C: Opengts Installation (Linux)

    FLEETPC-ARM-300 Quick Start Guide     Appendix C: OpenGTS Installation   (Linux)     Note: OpenGTS is used as a demonstration server to work with FLEETPC- ARM-100. It is not part of FLEETPC-ARM-100 product. Please check below link for more information on OpenGTS: http://www.opengts.org/...
  • Page 37 FLEETPC-ARM-300 Quick Start Guide         sudo a2enmod ssl sudo a2enmod rewrite sudo a2enmod suexec sudo a2enmod include sudo a2enmod dav_fs sudo a2enmod dav sudo /etc/init.d/apache2 restart      Disable ruby sudo vi /etc/mime.types   #application/x-ruby  ...
  • Page 38 FLEETPC-ARM-300 Quick Start Guide     export GTS_HOME=/usr/local/OpenGTS      Setup mysql JDBC wget -c   http://dev.mysql.com/get/Downloads/Connector-J/mysql-connector-java-5.1.1   8.tar.gz   tar xzvf mysql-connector-java-5.1.18.tar.gz   sudo cp mysql-connector-java-5.1.18-bin.jar $JAVA_HOME/jre/lib/ext/. sudo ln -s /usr/local/OpenGTS_2.6.0 /usr/local/OpenGTS    Download OpenGTS：   Download OpenGTS from http://www.opengts.org/...

  • Page 39: C-3 Change Opengts Map Provider To Google Map

    FLEETPC-ARM-300 Quick Start Guide          Show java prcess $GTS_HOME/bin/psjava      Installing “events.war” ant events   use tomcat manager to deploy   (assuming your PC IP address is 192.168.200.150)   http://192.168.200.150:8080/manager/html      HTTP Based Device Communication Servers (using the "gprmc" servlet) Building the "gprmc"...
  • Page 40     Appendix D: FLEETPC-ARM-300 Remote Access   To use FLEETPC-ARM-300 remote access function, you need a Ubuntu PC or Windows connected to FLEETPC-ARM-300 via LAN cable or WiFi. The FLEETPC-ARM-300 default IP address is 192.168.1.1 or 192.168.2.1.    ...
  • Page 41               2.) Run VNC server on FLEETPC-ARM-300. You can click X11VNC icon on Yocto desktop or type the following command on Yocto console: /usr/bin/x11vnc - display :0 (default TCP/IP port : 5900)    ...
  • Page 42 FLEETPC-ARM-300 Quick Start Guide                                                                 4.) Click “Create a new remote desktop file” → Enter Remote Desktop Profile as in the diagram below, and click “Connect”...
  • Page 43 FLEETPC-ARM-300 Quick Start Guide         5.) Once the connection is successful, you will see FLEETPC-ARM-300 desktop on Ubuntu.         Page 43...
  • Page 44 FLEETPC-ARM-300 Quick Start Guide       D-2 Access FLEETPC-ARM-300 from a remote Windows PC       1.) Download Real VNC software in Windows PC and install it.                      ...
  • Page 45 FLEETPC-ARM-300 Quick Start Guide                                                                 4.) Enter below connection property and click OK : VNC Server：192.168.1.1:5900 (default TCP/IP port is 5900)
  • Page 46 FLEETPC-ARM-300 Quick Start Guide           5.) Run VNC server on FLEETPC-ARM-300. You can click X11VNC icon on Yocto desktop or type the following command on Yocto console: /usr/bin/x11vnc - display :0 (default TCP/IP port : 5900)  ...
