Summary of Contents for Eaton PowerXL DE1

Page 1 Quick-Start-Guide 10/2015 AP040092EN PowerXL™ Quick-Start-Guide AP040092EN Title DE1 Quick-Start-Guide Product PowerXL™ DE1 1 – Fundamental – No previous experience necessary 2 – Basic – Basic knowledge of Variable Speed Starter recommended Level 2 3 – Advanced – Basic knowledge of Variable Speed Starter required 4 –...
Page 2 Configuration of the analog input ....................... 17 Configuration of digital input 3 (terminal 3) ....................17 DC braking ..............................18 Start-Mode and Auto Reset ......................... 18 Modbus ............................... 19 SmartWire ..............................19 Parameter list .............................. 20 AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 2...
Page 3: Danger! - Dangerous Electrical Voltage
– Never touch live parts or cable connections of the Variable Speed Starter after it has been disconnected from the power supply. Due to the charge in the capacitors, these parts may still be alive after disconnec- tion. Consider appropriate warning signs. AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 3...
Page 4: Disclaimer
Eaton’s experience and judgment and may not cover all contingencies. If further information is required, an Eaton sales office should be consulted. Sale of the product shown in this literature is subject to the terms and conditions outlined in the applicable Terms and Conditions for Sale of Eaton or other contractual agreement between Eaton and the purchaser.
Page 5: General
After removal of the START command (FWD or REV). In case the motor ramps to stop (P-05 = 1 = Default) the contact opens at speed zero.  Ramp times set to 5 s. AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 5...
Page 6: Environmental Conditions
Variable Speed Starter is enabled. If necessary, these functions can also be disabled. The Variable Speed Starter itself is still protected in this case but trips may occur. AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 6...
Page 7: Overvoltage Control
This function results in a short time delay between start signal and start of the motor. This function is not activated in default. If DC braking is required, the function can be activated. See further down in this Quick- Start-Guide AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 7...
Page 8: Status Leds
34… and reapplying it  With a rising edge of the start signal (FWD / REV)  automatically, where the DE1 is configured accordingly (see „Startmode and Auto Reset“)  via Modbus or SWD, if used AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 8...
Page 9: Configuration Module Dxe-Ext-Set
It can be plugged and unplugged when live. The module is not necessary to oper- ate DE1 after a parameter change. It can be removed after use. The settings are “stored mechanically” by the position of the switches and potentiometers. AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 9...
Page 10 Green: Settings of module are equal to • Yellow: Settings of module and DE1 are different • 3 flashes for 2 s each: settings are trans- ferred successfully • Flashing with 4 Hz: Potentiometer for Fixed Frequency active AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 10...
Page 11: Motor Protection
For that reason, a reinforced insulation between the thermis- tors and the motor windings is required not to weaken the overall insulation system of the PDS (Power Drive System). AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 11...
Page 12: Functions Of The Signals At The Control Terminals
Direction of rotation selected with DIR. L = Forward, H = Reverse ATTENTION: in this configuration a wire break at H-Signal (REV) leads to a reversion of the di- rection of rotation of the motor. AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 12...
Page 13: Configuration Of The Control Terminals
It is also possible to connect a thermistor to terminal 3. Details see “motor protection”. Mode 2 Fixed frequencies (1)  2 directions (FWD/REV)  Selection of fixed frequencies via binary coded in- puts (FF2 / FF2 AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 13...
Page 14 DOWN gets priority. Mode 7 Fixed frequencies (2)  1 direction (FWD)  External fault (EXTFLT). Details see Mode 1  Selection of fixed frequencies via binary coded in- puts (FF2 / FF2 AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 14...
Page 15  External fault (EXTFLT). Details see Mode 1  Enabling of the Variable Speed Starter with START Hint: In case of wire break at terminal 2 (DIR = REV) the motor will reverse automatically! AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 15...
Page 16: Full Parameter Access
In case access to additional parameters is needed, this can be achieved by using:  the optional keypad DX-KEY-LED (V1.2 and above)  the parameter software DrivesConnect. Free Download: http://www.drive-support-studio.com/OTS/Eaton/downloads/deploy/drivesConnect.htm  the communication system SmartWire DT in connection with the option module DX-NET-SWD3  Modbus RTU The Variable Speed Starter can be accessed via the RJ45 socket on front of the device.
Page 17: Configuration Of The Analog Input
The logic can be inverted with P-19 (DI3 Logic)  0  High = OK, Low = Fault (necessary for thermistor)  1  Low = OK, High = Fault AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 17...
Page 18: Dc Braking
The number of restart attempts is counted and if DE1 doesn’t restart, it trips after the final attempt. In this case reset has to be done manually. The counter of attempts can only be reset by removing the power from the DE1 device. AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 18...
Page 19: Modbus
Terminal 1 is used as hardware enable and requires a High signal to operate DE1 via SmartWire. For additional changes of the terminal configuration compared to the settings in default and for additional operating modes see manual MN040011EN. AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 19...
Page 20: Parameter List
Used to increase the applied motor voltage at low output frequen- P-11 27.0 r/w V-Boost 0.0 … 40.0 % 0.0 % cy, in order to improve low speed and starting torque. Excessive voltage boost levels may result in increased motor current AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 20...
Page 21 Value can be adjusted between f-min (P-02) and f-max (P-01). Selection via a digital control signal. Preset Fixed Frequency 2 P-21 r/w f-Fix2 … f 30 Hz Value can be adjusted between f-min (P-02) and f-max (P-01). AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 21...
Page 22 0 = Thermal memory enabled 1 = Thermal memory disabled P-34 918.0 r/w PDP-Address 1…63 Unique VSS address for communication network. Modbus Baudrate P-35 3222.0 r/w RS485-0 Baudrate 0…4 0 = 960 Bit/s 1 = 19.2 kBit/s AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 22...
Page 23 "hours" to "minutes and seconds" Switching frequency set with P-29 is displayed. The value may be P00-14 390.1 Actual Switching Frequency less than the one set with P-29 when the thermal management of AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 23...
Page 24 250.0 250.1 250.2 P00-20 DriveInformation Type details of the VSS 251.0 252.0 202.0 (*) Parameter numbers marked with an asterisk are not transferred in cases where the source and destinations ratings do not match. AP040092EN _DE1 Quick-Start-Guide www.eaton.eu Page 24...
