Alfa Network AWUS036ACM User Manual page 21

Step 3 Choose the Config Mode as Enrollee and click the Next icon on the screen.
Meanwhile, enter the PIN code of the adapter (here takes 33716435 in the screen for
example) into the configuration utility of the AP. For the detailed instructions of the AP
configuration, please refer to the User Guide of the AP.
Step 4 Click Start PIN on the following screen.
Step 5 When Figure 2-16 appears, the configuration is complete.
ALFA WiFi USB Adapter User Guide
Figure 2-17
Figure 2-18 Enrollee Mode
Figure 2-19 Start PIN
1 7
