Alfa Network AWUS036ACM User Manual page 19

I. PBC Method
If your Access Point is equipped with a push-button for Wi-Fi Protected Setup, you can connect
the adapter to the Access Point by Push-Button Configuration (PBC) method.
Step 1 Press the WPS button on your Access Point device.
Step 2 Click the Add to Profile icon on the screen as Figure 2-11.
Step 3 Select Push-Button Configuration (PBC) on the screen below.
Step 4 Click Start PBC.
Figure 2-12 Press the WPS Button
Figure 2-13 Push-Button Configuration
Figure 2-14 Start PBC
1 5
ALFA WiFi USB Adapter User Guide
WPS
