DoAll C-520NC Instruction Manual page 7

Segatrici
S.r.l
2.5. V
ISES
The saw vises are hydraulic. The clamping part of them have a tempered insert bolted. Besides, the hydraulic circuit that
controls the vises has a pressure reducer valve with a gauge to avoid to clamp with too much strength the material and de-
form it.
TAB 2.3
Description
On the length
On the perpendicularity
3. HOW TO USE THE INSTRUCTION MANUAL
3.1. W
HO SHOULD READ THE INSTRUCTION MANUAL
Description
Instruction Manual
Electrical Schematic
The electrical schematic is included in this manual and cannot be supplied separately.
3.2. W
HERE TO KEEP THIS MANUAL
This manual, that is provided along the machine in one copy, should be kept where the machine is located, in a safe and pro-
tected place, to be consulted if necessary.
3.3. S
TRENGTH OF THIS MANUAL
1. This manual reflects the state of the art at the time the machine was built, and cannot be considered replaceable by a
newer version.
2. This manual has full force for all the life of the machine it goes along.
3. The customer is not allowed to copy totally or partially this manual to reach goals different than the one of the origi-
nal manual, and to avoid that a partial documentation replaces the original one.
3.4. M
ANUAL UPDATE
The manufacturer does not have to update this manual if improvements are adopted on newer machines of the same kind of
the one this manual make reference to.
This manual will be updated by the manufacturer only if :
Instruction Manual
Cutting tolerances
mm
mm
TAB 3.1 Who should read the manual
Machine
C-520 NC
±0,15 mm / 500 mm
±0,2 mm /100 mm
?
Operator
Mechanical
Yes
No
Internal service
Electrical
Yes No
No Yes
Pag.7
Edition A
