Procom SL250TYLA-D Owner's Operation And Installation Manual page 15

1. Install legs and flex tube.
Lay the heater down on its back and remove
the regulator dustproof sticker and assemble the
gas line into the inlet hole on the regulator.
2. Install the decorating logs.
Fasten decorating logs 1 ¡¢
Insert the pinhole on the upper part of log 4 into the pin on the left side of log 1. Place the lower part
on the flat roof at the left side of log 3 (Figure 4).
Insert the pinhole on the upper side of log 5 into the pin on the right side of log 1. Place the lower
part on the flat roof at the right side of log 3 (Figure 5).
5. Install the heater according to the Installation in the owner's manual.
¡¢3 onto the correspondent angle iron (Figure 3).
¡¢2 ¡¢ ¡¢ ¡¢
¡¢ ¡¢ ¡¢ ¡¢
Figure 2
Figure 4
Figure 3
Figure5
15
Figure 1
