2.0 SAFETY

CAUTION
CAUTION
NOTICE
3.0 GENERAL INFORMATION
The CROSSFIRE monitor is the most rugged and innovative deck/portable master stream device ever off ered to the fi re service.
Attachment of the CROSSFIRE to the base is quick, easy, positive, and can be visually verifi ed. The release mechanism is locked
out by water pressure. The rotation lock is a simple lever which securely holds the CROSSFIRE monitor in position. An automatic
drain allows water to drain from the monitor when not in use.
The SAFE-TAK 1250 portable base, available in either single or double inlet confi gurations, has a revolutionary safety valve which
will reduce the fl ow area through the base by 90% if the SAFE-TAK base should leave the ground for any reason. This safety feature
reduces the risk of injury from an out of control master stream device.
3.1 VARIOUS MODELS AND TERMS
The CROSSFIRE Portable Monitor is an effi cient, compact and easy to maneuver portable monitor. This monitor can be mounted in
a pre-connected state on the truck-mounting bracket for achieving quick and eff ective initial attack.
The CROSSFIRE monitor is available in several diff erent models and inlet connections. Figures 3.1.1, 3.1.2, & 3.1.3 show the
CROSSFIRE monitor, Safe-Tak 1250 portable base, and truck mount adapter and identifi es the various parts and controls.
Carrying Handle
Elevation Pin Stop
Grease Fitting
Automatic Drain
Inlet
Safety Valve Handle
Anchor Strap
& Storage Cover
Leg Lock Knob
Stainless Steel Leg
Carrying Handle
Anchor
Attachment Point
©Copyright Task Force Tips, Inc. 2002-2018
Monitor must be properly connected to a hose and nozzle with matched threads. Mismatched or
damaged threads may cause leaking or uncoupling under pressure and could cause injury.
Dissimilar metals coupled together can cause galvanic corrosion that can result in the inability
to unscrew the threads or complete loss of thread engagement over time. Per NFPA 1962, if
dissimilar metals are left coupled together an anti-corrosive lubricant should be applied to the
threads. Also the coupling should be disconnected and inspected at least quarterly.
To prevent mechanical damage, do not drop or throw equipment.
CROSSFIRE MONITOR
SAFE-TAK 1250 BASE
Figure 3.1.2
Figure 3.1.1
4
Pressure Gauge
Elevation Control
Rotation Lock
Safety Plunger
Slide Bar
Pawls
Truck Mount Companion
Adaptor Flange
Figure 3.1.3
