Task Force Tips SAFE-TAK 1250 Operation And Maintenance Instructions page 2

1.0 MEANING OF SAFETY SIGNAL WORDS
2.0 SAFETY
3.0 GENERAL INFORMATION
3.1 VARIOUS MODELS AND TERMS
3.2 SPECIFICATIONS
3.2.1 MECHANICAL
4.0 CROSSFIRE DEPLOYMENT
4.1 QUICK CONNECT SWIVEL JOINT
4.2 INSTALLING MONITOR ON BASE
4.3 REMOVING MONITOR TOP FROM BASE
4.4 SIDE-TO-SIDE ROTATION AND ROTATION LOCK
4.5 ELEVATION CONTROL AND STOP PIN
4.6 AUTOMATIC DRAIN
4.7 TRUCK MOUNT BASE
4.8 TRUCK MOUNTING OF THE PORTABLE BASE
4.9 CROSSFIRE ® USEGAE
4.10 FLOWS AND PRESSURES
4.10.1 STACKED TIPS
4.10.2 AUTOMATIC MASTER STREAM NOZZLES
4.10.3 STREAM STRAIGHTENERS
4.10.4 PRESSURE LOSS
4.10.5 OPERATING ENVELOPE
4.11 TRANSPORTING MONITOR ON TRUCK MOUNT
BASE
5.0 SAFE-TAK 1250 BASE
5.1 SITE SELECTION
5.2 EXTENDING PORTABLE LEGS
5.3 RETRACTING PORTABLE BASE LEGS
5.4 PORTABLE BASE LEG SPIKES
5.5 PORTABLE BASE ANCHORING
5.6 PORTABLE BASE SAFELY VALVE
5.7 HOSE CONNECTION
5.8 PRESSURE RELIEF OPTION
5.9 PRESSURE RELIEF VALVE SETTING
©Copyright Task Force Tips, Inc. 2002-2018
Table Of Contents
6.0 PORTABLE BASE STORAGE
6.1 STORAGE BRACKET
6.1.1 INSTALLATION INSTRUCTIONS FOR
6.1.2 INSTALLATION INSTRUCTIONS WHERE
7.0 APPROVALS
8.0 DRAWINGS AND PART LISTS
8.1 MONITOR DRAWING AND PART LIST
8.2 SAFE-TAK 1250 DRAWING AND PART LIST
8.3 HIGH FLOW INLET OPTION
8.4 DOUBLE INLET OPTION
9.0 WARRANTY
10.0 MAINTENANCE
10.1 GREASING THE WORM GEAR
10.2 SERVICE TESTING
10.2.1 HYDRAULIC TEST
10.2.2 RELIEF VALVE TEST
10.2.3 SHUTOFF VALVE TEST
10.2.4 RECORDS
10.3 REPAIR
11.0 ANSWERS TO YOUR QUESTIONS
12.0 OPERATION and INSPECTION CHECKLIST
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Firefi ghting and Emergency Response are inherently dangerous activities
requiring proper training in their hazards and the use of extreme caution
at all times.
2. It is your responsibility to read and understand any user's instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Firefi ghting and /or Emergency Response and in the use, precautions, and
care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the manufacturer's
instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
FEMSA
2
BLIND MOUNTING
BACK OF MOUNTING SURFACE IS
ACCESSIBLE
DANGER
PERSONAL RESPONSIBILITY CODE
Fire and Emergency Manufacturers and Service Association
P.O. Box 147, Lynnfi eld, MA 01940 • www.FEMSA.org
LIX-030 January 8, 2018 Rev24
