STEP 3
Fasten Inside Chassis using two
#8-32 x 11/2" Flat Head Machine
Screw (item #5).
Check alignment before
fully tightening screws.
STEP 4
Connect Wire Harness (A) and tuck Connectors as shown (B).
STEP 5
Install Battery.
9V Battery
!
Optional - An additional #8
wood screw (provided) can
be installed to prevent the
interior trim from rotating
A
For optimal performance, always
use a good quality battery.
EN
B
