9. TECHNICAL INFORMATION

ELECTRICAL SPECIFICATIONS
Impedance balanced audio outputs
Main outputs level: +22 dBu
Output impedance: 440 Ω unbalanced
Digital-to-analog S/N ratio: 108 dB
(20–20,000 Hz)
Headphones output
Headphones out level: +22 dBu
Output impedance: 55 Ω
Audio inputs
Input level: +19 dBu
Audio input impedance: 11 kΩ
Analog-to-digital S/N ratio: 112 dB
(20–20,000 Hz)
Unit power consumption: 7 W typical
Compatible Elektron power supply: PSU-3b
32
HARDWARE
128 × 64 pixel OLED screen
MIDI In/Out/Thru with DIN Sync out
2 × 1/4" impedance balanced audio out
jacks
2 × 1/4" audio in jacks
1 × 1/4" stereo headphone jack
48 kHz, 24-bit D/A and A/D converters
Electrically isolated Hi-Speed USB 2.0 port
Power inlet: Center positive 5.5 × 2.5 mm
barrel jack, 12 V DC, 1 A
PHYSICAL SPECIFICATIONS
Sturdy steel casing
Dimensions: W 215 × D176 × H 63 mm
(8.5" × 6.9" × 2.5") (including knobs and feet)
Weight: approximately 1.49 kg (3.3 lbs)
100 × 100 mm VESA mounting holes. Use
M4 screws with a max length of 7 mm.
Maximum recommended ambient operating
temperature: +40˚C (+104˚F)
