Chapter 5
Setting Up the Server to Recognize the Logical Units
5.1
Recognizing Logical Units with the sd Driver
Example:
#
# Copyright (c) 1992, by Sun Microsystems, Inc.
#
#ident
"@(#)sd.conf
name="sd" class="scsi"
target=0 lun=0;
name="sd" class="scsi"
target=1 lun=0;
name="sd" class="scsi"
target=2 lun=0;
name="sd" class="scsi"
target=16 lun=0;
name="sd" class="scsi"
target=16 lun=1;
name="sd" class="scsi"
target=16 lun=2;
For direct connection
Set the "target=" value the same as the Loop-ID set in the [Set CA Parameters] window of ETERNUS Web
GUI or ETERNUSmgr.
The ETERNUS Web GUI or ETERNUSmgr Loop-ID is natively set as a hexadecimal value, which must be
converted to a decimal value for this setting.
For switch connection
Set the "target=" value the same as the target ID of the "fcp-bind-target" parameter set in the configuration
file. Refer to
5.1.2

Getting the Server to Recognize the Logical Units

The server now needs to use the new sd driver settings to recognize the logical units.
1
Reconfigure and reboot the server to get it to recognize the listed logical units. Execute the following
command.
# touch /reconfigure
# /usr/sbin/shutdown -y -g0 -i6
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
1.9
98/01/11 SMI"
:
:
"6.1 Setting Up the Parameters" (page
Copyright 2017 FUJITSU LIMITED
22).
19
P3AM-3712-15ENZ0
