Side View
The depth from the front of the top grille to the back of the
refrigerator cabinet is 25³⁄₈" (64.5 cm).
The power cord is 84" (213 cm) long.
The water line attached to the back of the refrigerator is 5 ft
(1.5 m) long.
Height dimensions are shown with leveling legs extended ¹⁄₈"
(3 mm) below the rollers.
³⁄₈
*83
"
(211.8 cm)
84" (213.4 cm)
Power Cord
*When leveling legs are fully extended to 1¹⁄₄" (3.2 cm) below
rollers, add 1¹⁄₈" (2.9 cm) to the height dimensions.
Top View
A
Model
Width A
35" (88.9 cm)
36
41" (104.1 cm)
42
47" (119.4 cm)
48

Product Dimensions

³⁄₈
25
"
(64.5 cm)
¹⁄₂
23
"
(59.7 cm)
¹⁄₂
*3
" (8.9 cm)
³⁄₈
25
"
(64.5 cm)
Front View
Width dimensions were measured from trim edge to trim
edge.
Height dimensions are shown with leveling legs extended ¹⁄₈"
(3 mm) below the rollers.
A
(see chart following)
Model
Width A
(Trim edge to trim edge)
36
36¹⁄₄" (92.1 cm)
42
42¹⁄₄" (107.3 cm)
48
48¹⁄₄" (122.6 cm)
*When leveling legs are fully extended to 1¹⁄₄" (3.2 cm) below
rollers, add 1¹⁄₈" (2.9 cm) to the height dimensions.
³⁄₈
*83
"
(211.8 cm)
9
