Side Tipping Radius (42" [106.7 cm] Models)
93"
(236.2 cm)
A. Tip this side only

Product Dimensions

Side View
The depth from the front of the top grille to the back of the
refrigerator cabinet is 25³⁄₈" (64.5 cm).
The power cord is 84" (213 cm) long.
The water line attached to the back of the refrigerator is 5 ft
(1.5 m) long. Height dimensions are shown with leveling legs
extended ¹⁄₈" (3 mm) below the rollers.
³⁄₈
*83
"
(211.8 cm)
84" (213.4 cm)
Power Cord
*When leveling legs are fully extended to 1¹⁄₄" (3.2 cm) below
rollers, add 1¹⁄₈" (2.9 cm) to the height dimensions.
www.dexpress.com
8
Cond Inst
A
³⁄₈
25
"
(64.5 cm)
¹⁄₂
23
"
(59.7 cm)
¹⁄₂
*3
" (8.9 cm)
Cond Inst
Page 7 of 18
Top View
36" (91.4 cm) Models
42" (106.7 cm) Models
Front View
Width dimensions were measured from trim edge to trim
edge.
Height dimensions are shown with leveling legs extended ¹⁄₈"
(3 mm) below the rollers.
36" (91.4 cm) Models
*When leveling legs are fully extended to 1¹⁄₄" (3.2 cm) below
rollers, add 1¹⁄₈" (2.9 cm) to the height dimensions.
Page 7 of 18
KBRO36FTX
3/24/2012
¹⁄₄
35
"
(89.5 cm)
³⁄₈
25
(64.5 cm)
¹⁄₄
41
"
(105 cm)
³⁄₈
25
"
(64.5 cm)
³⁄₈
*83
(211.8 cm)
¹⁄₄
36
" (92 cm)
KBRO36FTX
3/24/2012
"
"
