Technical data
10 Technical data
Supply voltage
Energy consumption
Power supply
Dimensions in cm
Housing
Interfaces
Memory capacity
Protection class
Temperature range
Display
Mounting
Weight
100 of 104
12V DC
approx. 3 watts
External wall power supply 12V DC
22.5 / 28.5 / 4 (W x H x D)
Plastic housing, passively ventilated
Ethernet RJ45 bushing 10/100MBit
RS485/RS422 combined
S0 impulse input (in accordance with DIN43864
and DIN62056)
Reset buttons
8 MB RAM + 2 GB SD RAM (internal only)
IP 20 (exclusively for inside use)
-10°C to 50°C
4 LEDs for status displays
Wall mounted
0.55 kg
200
Solar-Log
User Manual
