Controls, Indicators, and Connectors: Receiver
Name
AC Line Connector and
A
Fuseholder Module
Auxiliary Output
B
Connector
US, ECG, UA, and Mark
C Connectors
D Antenna Connector
E Equipotential Lug
Model 340 Telemetry System
2006920-001
Table 3-2. Receiver Rear Panel
Description
This module houses the AC-line input connector
and the main fuses for the receiver:
n
100–120 VAC: requires two, 0.25 A slow-blow
fuses.
n
220–240 VAC: requires two, 0.2 A time-lag
fuses.
This connector is used with 120 and 170 Series
Monitors only. Do not use this connection method
for Models 115, 116, 118, 145, 150, 151, and 155
Monitors.
This connector outputs the US, ECG, UA, and
Mark signals, acquired by telemetry, to a 120 or
170 Series Monitor. See the Model 340 Operator's
Manual for complete interconnection details.
As soon as any telemetry mode is detected, the
front panel of the 120 or 170 Series Monitor is
disabled and all front panel inputs are ignored.
In other words, telemetry and monitor modes
cannot be "mixed and matched'; you must use
telemetry only or direct monitoring only.
For proper operation with a 170 Series Monitor,
disconnect all transducers from the front panel
of the monitor.
These connectors are used with Models 115, 116,
118, 145, 150, 151, and 155 Monitors only. Do not
use this connection method for 120 and 170 Series
Monitors.
Each connector outputs the respective signal,
acquired by telemetry, to the fetal or maternal/fetal
monitor:
n
US: light grey connector which outputs the
ultrasound signal.
n
ECG: grey connector which outputs the FECG or
MECG signal.
n
UA: white connector which outputs the TOCO or
IUPC signal.
n
Mark: connector which outputs the Event Mark
signal.
See the Model 340 Opreator's Manual for complete
interconnection details.
Twist-on connector for attaching the receiver
antenna.
Binding post terminal directly connected to the
chassis for use as an equipotentiality connection.
