Receiver Rear Panel
A
120V ~ 50-60HZ 30W
0.25A SLOW BLOW
3-4
Controls, Indicators, and Connectors: Receiver
E
WARNING: TO REDUCE FIRE HAZARD
!
REPLACE FUSE AS MARKED.
ULTRASOUND
CONNECT TO
COROMETRICS
MONITORS ONLY
CAUTION
!
B
C
Note: Antenna shown removed.
Figure 3-2. Receiver Rear Panel
Model 340 Telemetry System
2006920-001
D
ANTENNA
ECG
UA
OUTPUTS TO MONITOR
Revision A
