Calibration - GE Medical Systems Corometrics 340 Service Manual

Revision A

Calibration

This section of the manual provides a calibration procedure which allows
authorized service personnel to perform an instrument alignment using
a minimum of test equipment. This procedure is not intended to replace
a complete instrument checkout and alignment as performed at the GE
Medical Systems Information Technologies factory. It should be
considered a performance check and troubleshooting guide to be used in
conjunction with other information supplied throughout this service
manual. It is important to mention, this section of the manual is not
intended as a substitute for proper professional training, or familiarity
with the Model 340. Only qualified service personnel should attempt
servicing the Model 340.
This chapter contains the following information:
FCC Service Information
Test Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Receiver Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmitter Calibration
Model 340 Telemetry System
2006920-001
Chapter 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
5
5-2
5-3
5-4
5-12
5-1
