- Page 1 FCC ID : PJILT32DW000 ATTACHMENT E. - USER’S MANUAL - REPORT NO. : HCT-F05-0705 HYUNDAI C–TECH...
- Page 3 Important Tip Image Retention Effect (Image Sticking) 1. Cause : - Image Retention Effect may come from displaying a still picture in certain period of time with at a certain area continuously, as the feature of LCD panel. This is caused due to brightness degradation. Many LCD manufacturers are trying to overcome this limitation.
- Page 4 HYUNDAI Vvuon Digital LCD TV Image Sticking Precaution When watching a still Image within motion pictures and Panorama/Wide/4:3 screen Panorama, Wide, 4:3 screen Box still image 1. Note : - When the central area of the screen and the screen edges are fixed, the different brightness level of the edges may cause image retention on the edges when watching for a long time - This phenomenon is the same matter to other LCD manufacturers.
- Page 5 Features Dual Scan/Multi-Viewing You can program analog TV broadcasting and digital TV broadcasting automatically at the same time for multi-viewing. A Wide Array of Screen Settings You can choose different screen settings depending on the type of program you are watching or the surrounding conditions (the outside weather conditions).
- Page 6 HYUNDAI Vvuon Digital LCD TV Table of Contents...
- Page 7 Safety Precaution The contents of this section are provided for the safety of users and their property. Please read the instructions carefully before using. WARNING If there is a persistent accumulation of dusts or water on the plug, please make sure to wipe it off using a dry cloth.
- Page 8 HYUNDAI Vvuon Digital LCD TV Safety instructions are divided into “Warning” and “Alert”. Their meanings are as follows. This icon is intended to alert the user to the presence of potential danger and important operating instructions. WARNING : When there is a possibility of serious injury if not observed.
- Page 9 Safety Precaution ........Continued from previous page The contents of this section are provided for the safety of users and their property. Please read the instructions carefully before using. WARNING Never attempt to open, fix, or modify your TV. - When there is a need for fixing, call a service center.
- Page 10 HYUNDAI Vvuon Digital LCD TV Safety instructions are divided into “Warning” and “Alert”. Their meanings are as follows. This icon is intended to alert the user to the presence of potential danger and important operating instructions. WARNING : When there is a possibility of serious injury if not observed.
- Page 11 Safety Precaution ........Continued from previous page The contents of this section are provided for the safety of users and their property. Please read the instructions carefully before using. WARNING Do not place toys and cookies, etc. on the TV, which may attract children’s attention. - If it falls over on children, it may cause serious injury.
- Page 12 HYUNDAI Vvuon Digital LCD TV Safety instructions are divided into “Warning” and “Alert”. Their meanings are as follows. This icon is intended to alert the user to the presence of potential danger and important operating instructions. WARNING : When there is a possibility of serious injury if not observed.
-
Page 13: Contents Of The Package
Contents of the Package When opening the package, please ensure to check the following accessories provided. Antenna Cable Power Cord (coaxial cable) Remote Control & 2 batteries User's Guide (1.5V AAA) Products Sold Separately If you want to purchase separately sold products, consult a service center, electronics shops, or parts seller. Scart cable S-video Cable Wall Mounting Support... - Page 14 HYUNDAI Vvuon Digital LCD TV Kensington Lock Anti-theft Device - This display unit supports Kensington standard security lock to prevent theft. - You should purchase the Kensington lock device personally, if you need. The security lock is available at an electronics shop.
- Page 15 How to Mount and Detach The Speakers You can attach the speakers to the base of the unit or use them separately. How to mount the speakers onto the base of the unit 1. Tilt the unit backward until its base faces to yourself (See page 12 How to adjust the view angle). 2.
- Page 16 HYUNDAI Vvuon Digital LCD TV How to adjust the view angle You can adjust the panel downward or upward at a 0~15 degree angle.
- Page 17 How To Install Wall Mount Support 1. Caution 1. Install on the vertical wall surface only. 2. Do not install on the following places to protect the performance of LCD TV and to prevent malfunction. - Near sprinkler detector - Near heating devices - Places where vibration or shock may be applied - Near high-voltage power line 3.
- Page 18 HYUNDAI Vvuon Digital LCD TV 4. Installation Method 1. Unscrew the screws fastened on 4 spots on the stand of TV. 3. Fix the Base Frame Assy on the wall with screws or nails. Insert fixing pin here. 2. Fasten the Fixing Panel Assembly on the back of panel as shown on the Figure (Tighten the screws in order of the number shown in the Figure).
-
Page 19: Parts Names And Functions
Parts Names and Functions Front View * This product image may be a bit different from the actual product. Volume buttons Power button Use these buttons for your desired sound level. Use this button to turn on or off the TV. These buttons also serve as the cursor of Remote sensor and power LED. -
Page 20: Rear View
HYUNDAI Vvuon Digital LCD TV Rear View * This product image may be a bit different from the actual product. Power switch Component 1 Video input terminal Digital Audio output terminal for coaxial cable Use this switch to turn on/off power. -
Page 21: Remote Control
Remote Control 1. POWER/STANDBY 2. MUTE This button is also used when setting up to use other external device. 3. PIP FUNCTIONS - PIP : Use this button for PIP On/Off. - INPUT : Use this button to select the input source of sub-picture. - SIZE : Use this button to select the size of sub-picture. - Page 22 HYUNDAI Vvuon Digital LCD TV Using buttons when in Memory Mode 18. PICTURE MODE The following buttons are used differently in each 19. SOUND MODE menu. (See pages 65~70 for more details.) 20. BOOK-MARK Power Saving Function when listening to music Use this button to select/deselect your frequently-used channel.
- Page 23 How to Watch Both Analog and Digital Broadcasts with a Single Antenna Connection Method You can watch both analog and digital broadcasts by connecting a single antenna. Make sure that the antenna cable is connected to ANT 1 (ANALOG/DTV). Indoor antenna (detached house) Antenna cable Indoor antenna...
- Page 24 HYUNDAI Vvuon Digital LCD TV How to Watch Both Analog and Digital Broadcasts with Two Antennas Connection Method Connect an analog antenna to ANT 1 terminal for analog source and a digital antenna to ANT 2 terminal for digital source. Please ensure to connect an antenna to a correct terminal. (If you connect an analog antenna cable to ANT 2, you cannot watch TV program.)
- Page 25 Before Connecting the Video/Audio Connections to External Devices... Please make sure to read the following information on connection to enjoy best picture quality. Video/Audio connectors Types of video/audio cable : ➀ DVI-D ➁ 15-Pin D-Sub ➂ COMPONENT ➃ S-VIDEO ➄ COMPOSITE Best picture quality is displayed in the following order.
- Page 26 HYUNDAI Vvuon Digital LCD TV How to Connect a VCR/Cable Receiver Connection Method Connect the Video cable or S-Video cable between Video/S-Video output terminal of VCR or Cable receiver and Video/S-Video input terminal of TV. (Connect the jacks to terminals in the same color.) Connect the Audio cable (Left: white, Right: red) between Audio output terminal of VCR or cable receiver and Audio input terminal of TV.
-
Page 27: How To Connect A Dtv Receiver Or Dvd Player
How to Connect a DTV Receiver or DVD Player Connection Method Connect the Video cable (Y, Pb, Pr) between output terminals (Y, Pb, Pr) of DTV receiver or DVD player and the input terminals (Y, Pb, Pr) of DTV/DVD (480i/480p/720p/1080i) on the rear of TV. (Connect the jacks to terminal in the same color.) Connect the Audio cable between Audio output terminal of DTV receiver or DVD player and Audio input terminal for DTV/DVD Audio on the rear of TV. - Page 28 HYUNDAI Vvuon Digital LCD TV How to Connect a Camcorder/Game Player Connection Method Connect the Video/S-Video cable between Video/S-Video output terminal of Camcorder/Game player and Video/S-Video input terminal of TV. (Connect cables and terminal in the same colors.) Connect the Audio cable (Left-white, Right-red) between Audio output terminal of Camcorder/Game player and Audio input terminal of TV.
- Page 29 How to Connect to a PC Connection Method Connect the PC signal cable (15-pin D-sub) between the output terminal of PC and the D-sub input terminal of Connect the Audio cable between Audio output terminal of PC and Audio input terminal for PC on the rear of TV.
- Page 30 HYUNDAI Vvuon Digital LCD TV Resolutions Supported in PC Resolution Horizontal frequency Vertical frequency 31.47 70.09 640 x 350 37.86 85.08 31.47 59.94 37.86 72.80 640 x 480 37.50 75.00 43.27 85.01 720 x 400 31.47 70.08 37.88 60.32 48.08 72.18...
- Page 31 How to Connect an External Visual Device You can connect your TV to other visual device to watch two TV programs at the same time. Connection Method Connect the Composite Video cable between Video input terminals of an external device and the Video output terminals for Video on the rear of TV.
- Page 32 HYUNDAI Vvuon Digital LCD TV How to Use Digital Sound Connection Method Connect the coaxial cable or optical cable to the digital audio output terminal for coaxial cable or SPDIF optical digital audio output terminal on the rear of TV.
-
Page 33: How To Select The Picture Mode
How to Select the Picture Mode Users can automatically adjust the picture mode according to the input mode. Press Menu button. P I C T U R E MODE STANDARD Menu items appear on the screen. CUSTOM COLOR TEMP STANDARD ASPECT RATIO WIDE NOISE REDUCT... -
Page 34: How To Set The Desired Picture
HYUNDAI Vvuon Digital LCD TV How to Set the Desired Picture Users can manually adjust their desired picture. Press Menu button. P I C T U R E MODE USER 1 Menu items appear on the screen. CUSTOM COLOR TEMP... - Page 35 How to Adjust the Color Temperature of the Screen Users can manually adjust their desired color temperature. Press Menu button. P I C T U R E MODE STANDARD Menu items appear on the screen. CUSTOM COLOR TEMP STANDARD ASPECT RATIO WIDE NOISE REDUCT Press...
- Page 36 HYUNDAI Vvuon Digital LCD TV How to Select the Aspect Ratio Users can manually adjust the size of the screen. Press Menu button. P I C T U R E MODE STANDARD Menu items appear on the screen. CUSTOM COLOR TEMP...
- Page 37 AUTO (This is applied in digital broadcasting input mode only.) The screen size automaticaly changes according to a signal source received (General broadcast 4:3, Wide broadcast 16:9) WIDE General broadcast picture is adjusted to 16:9. Normal 4:3 general picture size Panorama Picture size for panorama video ZOOM 1...
- Page 38 HYUNDAI Vvuon Digital LCD TV How to Watch the PIP This function allows you to watch the PIP or TWIN mode. Press Menu button. P I C T U R E MODE STANDARD Menu items appear on the screen. CUSTOM...
- Page 39 How to Set the INPUT for the Sub-Picture This function is available only in the PIP mode. P I C T U R E Press Up and Down buttons to move to SOURCE MODE SMALL SOURCE Press Left and Right buttons to select SOURCE . The list of sub-picture sources appears.
- Page 40 HYUNDAI Vvuon Digital LCD TV How to Set the channel of the Sub-picture Channel : Press the button. This is applied only when the sub-picture is displayed. How to Change the Position of the Sub-picture : Press the button. Bottom Right Corner...
- Page 41 How to Reduce Noise Press Menu button. P I C T U R E MODE STANDARD Menu items appear on the screen. CUSTOM COLOR TEMP STANDARD ASPECT RATIO WIDE NOISE REDUCT Press button to select MOVE SELECT EXIT Press Up and Down buttons to move to NOISE REDUCT . P I C T U R E MODE STANDARD...
