Chuango AW1 Plus User Manual page 26

Door/ Window Contact
Power Supply
Static Current
Alarm Current
Transmitting Distance
Radio Frequency
Housing Material
Operating Condition
Transmitter Dimensions
Magnet Dimensions
Pet-immune PIR Motion Detector
Power Supply
Static Current
Alarm Current
Detection Scope
Pet Immunity
Transmitting Distance
Radio Frequency
Housing Material
Operation Condition
Detector Dimensions
Bracket Dimensions
23
DC 1.5V (1.5V AA LR6 battery x 1pc)
<35 uA
<40 mA
<80 m (open area/no interference)
315MHz or 433.92 MHz
ABS Plastic
Temperature 0°C~+55°C
Relative Humidity <80% (non-condensing)
71 x 34 x 17.5 mm (L x W x H)
51 x 12 x 13.5 mm (L x W x H)
DC 3V (1.5V AA LR6 battery x 2pcs)
<13 uA
<20 mA
8m/110°
<25kgs
<80 m (open area/no interference)
315MHz or 433.92 MHz
ABS Plastic
Temperature 0°C~+55°C
Relative Humidity <80% (non-condensing)
108 x 52 x 36.8 mm (L x W x H)
52 x 30 x 26.5 mm (L x W x H)
