9082 9082 HD/SD Frame Sync Product Manual Cobalt Digital Inc. 2406 E. University Ave. Urbana, IL 61802 Voice 217.344.1243 • Fax 217.344.1245 www.cobaltdigital.com 9082-OM (V4.4)
Page 2
Furthermore, Cobalt Digital Inc. reserves the right to make changes to any products herein to improve readability, function, or design. Cobalt Digital Inc. does not assume any liability arising out of the application or use of any product or circuit described herein.
Page 4
DashBoard™ User Interface ............... 3-3 ® Cobalt Remote Control Panel User Interfaces .......... 3-4 Accessing the 9082 Card via Remote Control ............3-5 Accessing the 9082 Card Using DashBoard™ ........... 3-5 ® Accessing the 9082 Card Using a Cobalt Remote Control Panel ..... 3-6 Checking 9082 Card Information................
Chapter 1 Overview This manual provides installation and operating instructions for the 9082 HD/SD Frame Sync card (also referred to herein as the 9082). This manual consists of the following chapters: Chapter 1, “Introduction” – Provides information about this manual •...
The Software Version of your card can be checked by viewing the Card Info menu in DashBoard™. See Checking 9082 Card Information (p. 3-7) in Chapter 3, “Operating Instructions” for more information. You can then check our website for the latest software version currently released for the card as described below.
Introduction Manual Conventions Manual Conventions In this manual, display messages and connectors are shown using the exact name shown on the 9082 itself. Examples are provided below. Card-edge display messages are shown like this: • Ch01 Connector names are shown like this: SDI OUT •...
Cards with many heat-producing components should be arranged to avoid areas of excess heat build-up, particularly in frames using only convection cooling. If required, make certain Rear I/O Module(s) is installed before installing the 9082 into the CAUTION frame slot.
The input/output complement listed above represents the maximum capability of the 9082. The practical input/output complement is determined by the par- ticular Rear I/O Module used with the 9082. Refer to 9082 Rear I/O Modules (p. 1-11) for more information.
(frame having valid SAV and EAV codes). Note: Although the 9082 passes all four groups of embedded audio, the 9082 frame sync function is not ideally suited for streams carrying audio because the 9082 does not have tracking embedded audio delay found on our cards spe- ®...
Page 12
9082 Functional Description Timecode Processor (See Figure 1-2.) This function provides for extraction of timecode data from the input video, and in turn re-insertion of timecode data into the output SDI. The function can monitor the SDI video input of the card for supported timecode formats, and then select and prioritize among SDI VITC, SDI ATC VITC, and SDI ATC LTC timecode sources.
MFC-8320-N network controller card installed. • DashBoard™ and the Remote Control Panels provide network control of the 9082 as shown. The value displayed at any time on the card, or via DashBoard™ or a Control Panel is the actual value as set on the card, with the current value displayed being the actual value as effected by the card.
Page 14
Chapter 3,“Operating Instructions”. Note: Some of the 9082 functions described in this manual are available only when ® using the DashBoard™, or Cobalt OGCP-9000 or OGCP-9000/CC Remote Control Panel user interfaces.
Rear I/O Module; the unused inputs and outputs remain unterminated and not available for use. The full assortment of 9082 Rear I/O Modules is shown and described in 9082 Rear I/O Modules (p. 2-4) in Chapter 2, “Installation and Setup”.
Technical Specifications Video Formats Supported by the 9082 The 9082 supports all current SMPTE standard SD and HD video formats. Table 1-1 lists and provides details regarding the video formats supported by the 9082. Table 1-1 Supported Video Formats Item...
Page 17
> 12 dB at 270 MHz – 1.485 GHz Signal Level: 800 mV ± 10% DC Offset: 0 V ± 50 mV Jitter (HD): < 0.15 UI (all outputs) Jitter (SD): < 0.10 UI (all outputs) Overshoot: < 0.2% of amplitude 1-13 9082-OM (V4.4) 9082 PRODUCT MANUAL...
Page 18
486i 29.97 (NTSC); 575i 25 (PAL) Signal Level: 1 Vp-p nominal Signal Type: Analog video sync (black burst or tri-level) Impedance: 75 Ω Return Loss: > 30 dB to 30 MHz Allowable Maximum DC on Ref Input: ±1.0 V 1-14 9082 PRODUCT MANUAL 9082-OM (V4.4)
(1) year. Cobalt Digital Inc.'s (“Cobalt”) sole obligation under this warranty shall be limited to, at its option, (i) the repair or (ii) replacement of the product, and the determination of whether a defect is covered under this limited warranty shall be made at the sole discretion of Cobalt.
Contact Cobalt Digital Inc. Contact Cobalt Digital Inc. Feel free to contact our thorough and professional support representatives for any of the following: Name and address of your local dealer • Product information and pricing • Technical support • Upcoming trade show information •...
Note: If installing the 9082 in a slot with no rear I/O module, a Rear I/O Module is required before cabling can be connected. Refer to Installing a Rear I/O Mod- ule (p. 2-3) for rear I/O module installation procedure.
Page 22
Installing the 9082 Into a Frame Slot CAUTION If required, make certain Rear I/O Module(s) is installed before installing the 9082 into the frame slot. Damage to card and/or Rear I/O Module can occur if module installation is attempted with card already installed in slot. Note: Check the packaging in which the 9082 was shipped for any extra items such as a Rear I/O Module connection label.
Install a Rear I/O Module as follows: On the frame, determine the slot in which the 9082 is to be installed. In the mounting area corresponding to the slot location, install Rear I/O Module as shown in Figure 2-1.
Lightly tighten captive screw. DSCN3487A.JPG Figure 2-1 Rear I/O Module Installation 9082 Rear I/O Modules Table 2-1 shows and describes the full assortment of Rear I/O Modules specifically for use with the 9082. 9082 PRODUCT MANUAL 9082-OM (V4.4)
Page 25
• HD/SD-SDI reclocked input copies ( RCK OUT 1 and RCK OUT 2 • Buffered SDI coaxial outputs ( SDI OUT 1 and SDI OUT 2 Note: RM20-9082-A/S Rear I/O Module compatible only with 20-slot frames. RM20-9082-AS.PNG 9082-OM (V4.4) 9082 PRODUCT MANUAL...
® contact Cobalt as listed in Contact Cobalt Digital Inc. (p. 1-16). • If installing a card in a frame already equipped for, and connected to DashBoard™, no network setup is required for the card. The card will be dis- covered by DashBoard™...
The format in which the 9082 functional controls, indicators, and displays appear and are used varies depending on the user interface being used. Regardless of the user interface being used, access to the 9082 functions (and the controls, indicators, and displays related to a particular function) follows a...
Note: When a setting is changed, settings displayed on DashBoard™ (or the Remote Control Panel) are the settings as effected by the 9082 card itself and reported back to the remote control; the value displayed at any time is the actual value as set on the card.
GUI drop-down lists. (In this manner, the setting effected using controls and selection lists displayed in DashBoard™ are comparable to the submenu items accessed and committed using the 9082 card edge controls. DashBoard Tabs...
Control Panel are comparable to the submenu items accessed and committed using the 9082 card edge controls.) Figure 3-3 shows accessing a function submenu and its parameters (in this example, “Video Proc”) using the Control Panel as compared to using the...
On the computer connected to the frame LAN, open DashBoard™. As shown below, in the left side Basic View Tree locate the Network Controller Card associated with the frame containing the 9082 card to be accessed (in this example, “MFC-8320-N SN: 00108053”).
Accessing the 9082 Card via Remote Control Card Access/Navigation Card Info Card Function Submenu Tree Pane Pane and Controls Pane ® Accessing the 9082 Card Using a Cobalt Remote Control Panel Press the Select Device key and select a card as shown in the example below.
Checking 9082 Card Information Checking 9082 Card Information The operating status and software version the 9082 card can be checked using DashBoard™ or the card edge control user interface. Figure 3-4 shows and describes the 9082 card information screen using DashBoard™ and accessing card information using the card edge control user interface.
ATC_VITC on line 9/8 and Dolby Metadata = 13 CC = 10 AFD (now on line 18) AFD = 18 Dolby Metadata = 13 resolved Card n Card 1 Figure 3-5 Example VANC Line Number Allocation Conflict and Resolution 9082 PRODUCT MANUAL 9082-OM (V4.4)
9082 Function Submenu List and Descriptions 9082 Function Submenu List and Descriptions Table 3-2 individually lists and describes each 9082 function submenu and its related list selections, controls, and parameters. Where helpful, examples showing usage of a function are also provided. Table 3-2 is primarily based upon using DashBoard™...
9082 Function Submenu List and Descriptions Table 3-2 9082 Function Submenu List Provides the following Video Proc parametric controls. • Video Proc Video Proc (On/Off) provides master on/off control of all Video Proc functions. • When set to Off, all processing is bypassed.
Operating Instructions 9082 Function Submenu List and Descriptions Table 3-2 9082 Function Submenu List — continued Allows assignment of AFD (Active Format Description) codes to the SDI output video. Note: This function only marks the SDI output with an AFD code. Actual AFD processing must be performed by a downstream card or system that recognizes an AFD code assigned here.
Page 38
Provides video Frame Sync select and offset tools. Framesync Note: Because the 9082 does not have audio controls and the tracking embedded audio delay found on cards designed specifically to also include audio processing, noticeable audio glitches may occur when processing asynchronous inputs.
Page 39
Operating Instructions 9082 Function Submenu List and Descriptions Table 3-2 9082 Function Submenu List — continued (continued) • Minimum Latency Control When Framesync is enabled, specifies the smallest amount of latency allowed by the frame sync (latency measurement in output video frames).
9082 Function Submenu List and Descriptions Table 3-2 9082 Function Submenu List — continued (continued) • Loss of Input Signal Selection In the event of input video Loss of Signal (LOS), determines action to be taken as follows: • Disable Outputs: Disable all outputs.
Operating Instructions 9082 Function Submenu List and Descriptions Table 3-2 9082 Function Submenu List — continued Provides timecode data extraction from various sources, and provides formatting and re-insertion controls for inserting the timecode into the output video. Timecode Shown below is an example in which received SDI video with SDI VITC waveform timecode is to be converted to SDI ATC_VITC timecode data.
Page 42
9082 Function Submenu List and Descriptions Table 3-2 9082 Function Submenu List — continued (continued) • Timecode Source Status Displays Displays the current status and contents of the three supported timecode formats shown to the left. • If a format is receiving timecode data, the current content (timecode running count and line number) is displayed.
Page 43
Operating Instructions 9082 Function Submenu List and Descriptions Table 3-2 9082 Function Submenu List — continued (continued) • Offset Controls Allows the current timecode count to be advanced or delayed on the output video. • Offset Advance or Delay selects offset advance or delay.
Page 44
9082 Function Submenu List and Descriptions Table 3-2 9082 Function Submenu List — continued (continued) • HD ATC_LTC Insertion Control For HD output, enables or disables ATC_LTC timecode insertion into the output video, and selects the line number for ATC_LTC timecode data.
To order features and obtain a license key, contact Cobalt sales at sales@cobaltdigital.com or at the contact information in Contact Cobalt Digital Inc. in Chapter 1, “Introduction”. Please provide the “SSN” number of your card (displayed in the Card Info pane) when contacting us for your key.
Page 46
9082 Function Submenu List and Descriptions Table 3-2 9082 Function Submenu List — continued (continued) • Preset Save stores all current card control settings to the currently selected preset. • Preset Save and Load (For example, if Preset 1 is selected in the Selected Preset drop-down...
Operating Instructions 9082 Function Submenu List and Descriptions Table 3-2 9082 Function Submenu List — continued (continued) • Preset Name With one of 16 presets selected, provides for entry of custom name for the preset (as shown in example below).
Error and Failure Indicator Overview The 9082 card itself and its remote control systems all (to varying degrees) provide error and failure indications. Depending on how the 9082 card is being used (i.e, standalone or network controlled through DashBoard™ or a Remote Control Panel), check all available indications in the event of an error or failure condition.
Page 49
Four blue LEDs indicate the input signal raster format being received and locked onto by the 9082 (1080, LEDs 720, 625, 525). Continuous cycling of the LEDs indicates the 9082 has not locked onto a particular format (as in the case of no signal input).
Page 50
Specific errors are displayed in the Card Info pane (in this example “No connection to device” indicating 9082 card is not connecting to frame/LAN). If the 9082 card is not connecting to the frame or LAN, all controls are grayed-out (as shown in the example here).
Page 51
CDI-9082 RCVR21” in this (in this example, all example, Card Info is shown indications are OK) for 9082 card in slot 6 Where applicable, additional status is displayed (as shown in this example) Figure 3-8 Selecting Specific Cards for Card Info Status Display 3-25 9082-OM (V4.4)
Item Checks Verify power presence and • On both the frame Network Controller Card and the 9082, in all cases when power is characteristics being properly supplied there is always at least one indicator illuminated. Any card showing no illuminated indicators should be cause for concern.
In the majority of cases, most errors are caused by simple errors where the 9082 is not appropriately set for the type of signal being received by the card. Note: The error indications shown below are typical for the corresponding error con- ditions listed.
The Cobalt Digital Inc. Technical Support Department will continue to provide advice on any product manufactured by Cobalt Digital Inc., beyond the warranty period without charge, for the life of the product. See Contact Cobalt Digital Inc. (p. 1-16) in Chapter 1, “Introduction“ for contact information. 3-28 9082 PRODUCT MANUAL 9082-OM (V4.4)
Page 56
Cobalt Digital Inc. 2406 E. University Ave. Urbana, IL 61802 Voice 217.344.1243 • Fax 217.344.1245 www.cobaltdigital.com 9082-OM (V4.4) Printed in USA...
