- Page 1 Cobalt Digital Inc. 9033-SD Standard Definition Analog Video Converter with Audio Embedding Owner’s Manual 9033-SD-OM Version: 1.1...
- Page 2 9033-SD • • • • Owner’s Manual • Cobalt Part Number: 9033-SD-OM • Document Version: 1.1 • Printed in the United States. • Last Author: MWB • Printing Date: 7/7/2008 3:10 PM The information contained in this Owner’s Manual is subject to change without notice or obligation. Copyright ©...
-
Page 3: Important Safety Instructions
Important Regulatory and Safety Notices Before using this product and any associated equipment, refer to the “Important Safety Instructions” listed below so as to avoid personnel injury and to prevent product damage. Products may require specific equipment, and /or installation procedures be carried out to satisfy certain regulatory compliance requirements. - Page 4 Environmental Information The equipment that you purchased required the extraction and use of natural resources for its production. It may contain hazardous substances that could impact health and the environment. To avoid the potential release of those substances into the environment and to diminish the need for the extraction of natural resources, Cobalt Digital encourages you to use the appropriate take-back systems.
-
Page 5: Table Of Contents
Contents Introduction In This Chapter...........................6 A Word of Thanks........................6 Overview............................6 Functional Block Diagram ......................7 Supported Audio and Video Formats ..................8 Input and Output Video ....................8 Embedded Audio ......................8 Analog Audio.......................9 Discrete AES Audio Input ...................9 AES Audio Input Advanced Features ..................9 AES Sample Rate Converter Bypass................9 Low latency AES Passthrough ..................9 Documentation Terms ........................9... -
Page 6: Introduction
Introduction In This Chapter This chapter includes the following sections: • A Word of Thanks • Overview • Functional Block Diagram • Supported Audio and Video Formats • Documentation Terms A Word of Thanks Congratulations on choosing the openGear 9033-SD Standard Definition Analog to Digital Converter with Audio Embedding. -
Page 7: Functional Block Diagram
Audio rates are always 48kHz nominally but discrete AES inputs pass through sample rate converters to align them with the output timing. Output AES is always precisely locked in time with the output video. Analog audio is differential input and sampled at 48 kHz with 0 dbFS digital equivalent to +24 dBu analog. -
Page 8: Supported Audio And Video Formats
Video Video Video Proc: Gain, Lift, Saturation, Phase Analog to SD Analog Audio Control: Digital Video Conversion Serializer Audio SD SDI and Cable Routing Embed Output Diff. Analog Driver 8 channels Audio A/D Gain Polarity 8 pairs Decode 16 channels and SRC 9033-SD Block Diagram Figure 1. -
Page 9: Analog Audio
Analog Audio The 9033-SD supports 8 channels differential analog audio. The analog audio is encoded in such a way as to make +24 dBu (analog) equivalent to 0 dBFS (digital). Analog audio conversion can be disabled to reduce power consumption. Discrete AES Audio Input The 9033-SD can accept 16 channels (8 pairs) of discrete AES audio on 75 ohm BNC connections. -
Page 10: Installation And Setup
Installation and Setup In This Chapter This chapter includes the following sections: • Static Discharge • Unpacking • Rear Module Installation (Optional) • Board Installation • BNC Connections • Menu Structure • Factory Defaults Static Discharge Whenever handling the card and other related equipment, please observe all static discharge precautions as described in the following note: Static discharge can cause serious damage to sensitive semiconductor devices. -
Page 11: Rear Module Installation (Optional)
Rear Module Installation (Optional) If you are installing the card in a 8310-C-BNC or 8310-BNC frame (one with a 100 BNC rear module installed across the entire back plane), skip this section. If you are installing the card into a slot with no rear module, you should have ordered and received a 8310-RM-10 Rear Module with your card. -
Page 12: Board Installation
Board Installation Use the following steps to install the card in the openGear 8310 frame: Refer to the Owner’s Manual of the openGear 8310 frame to ensure that the frame is properly installed according to instructions. Heat and power distribution requirements within a frame may dictate specific slot placement of cards. -
Page 13: Card Control And Status
Card Control and Status Card Status The card indicates the status of the input signal with the four blue LEDs labled with the different supported formats (625, 525). When the card has locked to a particular input format, that LED will be illuminated. - Page 14 Proc Phase This is Chroma (C channel) phase adjustment, expressed in degrees, ranging from –360 to +360 in steps of one degree. Audio Submenu Menu Structure Parameter Type Embd Grp1 Enbl Embedded Group Enable Ch01- Output Source Ch04 Gain Output Gain (x4) Output Polarity Grp2...
-
Page 15: Save Settings
Tone Frequency This sets the frequency of the test tone for each of the four tone generators. Each of the four tone generators TG1 – TG4 can be set to a different frequency, and are available as audio sources for the embedded or AES audio outputs. - Page 16 Information Submenu Menu Structure Parameter Type Info +POW Positive Watts Consumed -POW Negative Watts Consumed SWR# Software Release Number SWB# Software Build Number Positive Watts Consumed A read only indication of power consumed by the card from the frames +12V rail. Negative Watts Consumed A read only indication of power consumed by the card from the frames +-7.5V rail.
-
Page 17: In This Chapter
Remote Control In This Chapter This section provides a detailed explanation on using remote control functions with your card. DashBoard Control System Software The DashBoard Control System enables you to monitor and control openGear frames and controller cards from a computer. - Page 18 Menu Item Format Description Enable Enables or disables the Group Enable entire group of 4 channels. Disable Embedded 1-16 Chooses the source for the embedded audio. The Source AES 1-16 source for each channel (per channel) Analog 1-8 can be chosen separately. Embedded Silence Audio Group...
- Page 19 Menu Item Format Description Composite Selects the format of input SD analog video, so the decoder can properly YPbPr BetaCam SD Input Type decode the signal. YPbPr MII Video Signal Controls YPbPr SMPTE Specifies the amount of SD Composite setup (pedestal) in the 0.0 or 7.5 IRE of Setup Contains input video.
-
Page 20: Technical Specifications
Technical Specifications Table 4. Card - Technical Specifications Number of Inputs Differential, Common Mode Rejection (5V AC) Input Type Composite, Component YPbPr (BetaCam™, MII™, Video Inputs SMPTE/N10), RGB, and Y/C 12-Bits Conversion Bit Depth 5-Line Adaptive Comb or Notch Filter SD Color Separation Analog Video Y- 0-30MHz ±... - Page 21 4 Balanced Analog Audio Number of Inputs Phoenix 3-pin Connector 48KHz (free run or locked to the reference) Sampling Rate Analog Audio +24dBu => 0dBFS Signal Level Input Total Power Consumption <12W Other Warranty Five Year Transferable Specifications are subject to change without notice. 9033-SD Owner’s Manual •...
-
Page 22: Service Information
Service Information In This Chapter This chapter includes the following sections: • Troubleshooting Checklist • Warranty and Repair Policy Troubleshooting Checklist Routine maintenance to this openGear product is not required. In the event of problems with your card, the following basic troubleshooting checklist may help identify the source of the problem. If the module still does not appear to be working properly after checking all possible causes, please contact your openGear products distributor, or the Technical Support department at the numbers listed under... -
Page 23: Warranty And Repair Policy
Warranty and Repair Policy The openGear card is warranted to be free of any defect with respect to performance, quality, reliability, and workmanship for a period of FIVE (5) years from the date of shipment from our factory. In the event that your Cobalt Digital Inc. card proves to be defective in any way during this warranty period, Cobalt Digital Inc. -
Page 24: Ordering Information
Ordering Information 9033-SD and Related Products Your 9033-SD Standard Definition Analog to Digital Converter with Audio Embedding is a part of the openGear family of products. Cobalt Digital offers a full line of openGear terminal equipment including distribution, conversion, monitoring, synchronizers, encoders, decoders, embedders, and de-embedders, as well as analog audio and video products. - Page 25 Notes: 9033-SD Owner’s Manual • • • • (V 1.1) Page 25 of 26...
-
Page 26: Contact Us
Contact Us Contact Cobalt Digital Inc. General Business Office 217.344.1243 and Technical Support PHONE 217.344.1245 General Information Info@cobaltdigital.com E-MAIL Sales Information Sales@cobaltdigital.com 2406 East University Avenue POSTAL Cobalt Digital Inc. Urbana, IL 61802 USA SERVICE Visit us at the Cobalt Digital Inc. website. http://www.cobaltdigital.com/ •...
