Cascade installation example.
Remove JP1 jumper from all of the EL562 monitor
modules (see page 81), except on the one
where the twisted pair cable finishes
(don't uses the video output).
Distributed installation example.
Remove JP1 jumper from all of the video distributors
and EL562 monitor modules (see page 81),
except on the ones where the twisted pair cable
finishes (don't use the video output).
IMPORTANT.
If the system has one door panel only,
override the wiring to the second door panel.
If the system has more than one door panel, wire
the rest of panels as shown on the diagram.
FA-805
PRI SEC
230110 0 ~ ~ -
+
Main
SW2
- AP - - +
CV2 CV1 +12
INSTALLATION DIAGRAMS
O
Access door panel
M
CN2
-
+ D A A V V
out in in- in+
ne or several accesses with
twisted pair.
EL562
JP1
_
+ A D
SW1
V V
Malla
out+ out-
V M
p p
