Icom IC-M25 Instruction Manual page 15

SCAN INDICATOR (p. 15)
LOCK ICON (p. 13)
Appears when the Lock function is turned ON.
DUALWATCH/TRI-WATCH INDICATORS (p. 16)
"DW" appears during Dualwatch.
"TW" appears during Tri-watch.
DUPLEX INDICATOR
Appears when a duplex channel is selected.
SUB CHANNEL READOUT
Displays Channel 16 during a priority scan, Dualwatch
or Tri-watch. (p. 16)
Displays the Set mode item while in the Set mode. (p. 17)
SQUELCH/ VOLUME LEVEL ICON
Displays the squelch/volume level.
"SQL" blinks while adjusting the squelch level. (p. 10)
"VOL" blinks while adjusting the volume level. (p. 10)
The bars repeatedly appear in ascending order when
the Volume Loud function is turned ON. (p. 12)
The bars blink while the Volume Mute function is turned
ON. (p. 12)
CHANNEL NUMBER READOUT
Displays the selected operating channel number.
CHANNEL GROUP ICON
Displays the selected channel group.
PANEL DESCRIPTION
WEATHER CHANNEL/WEATHER ALERT ICONS
"WX" appears when the weather channel group is se-
lected.
" " appears while the Weather Alert function is turned
ON, and blinks when the alert tone is received.
LOW POWER ICON (p. 11)
"LOW" appears when the low TX power is selected.
"LOW" blinks when switching to the low power mode is
forced because of a high temperature error or low volt-
age.
3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
7
