B
LED and beeper indications
The scanner's beeper sounds and its top multi-color LED illuminates to indicate various functions or errors. An
optional "green spot" also performs useful functions. The following tables list these indications. One
exception to the behaviors listed in the tables is that the scanner's functions are programmable, and so may
or may not be turned on. For example, certain indications such as the power-up beep can be disabled using
programming barcode labels.
Indicator
Power-up beep
Good read beep
ROM failure
Limited scanning label read
Scanner active mode
Scanner disabled
Green spot
1
flashes
momentarily
1
Except when in sleep mode or when a Good Read LED Duration other than 00 is selected.
Programming mode - The following indications ONLY occur when the scanner is in programming mode.
Indication
Label programming mode entry A valid programming label has
Label programming mode
rejection of label
Label programming mode
acceptance of partial label
Description
The scanner is in the process of
powering up.
A label has been successfully
scanned.
There is an error in the
scanner's software/
programming.
Indicates that a host
connection is not established.
The scanner is active and ready
to scan.
The scanner has been disabled
by the host.
Upon successful read of a label,
the software turns the green
spot on for the time specified
by the configured value.
Description
been scanned.
A label has been rejected.
In cases where multiple labels
must be scanned to program
one feature, this indication
acknowledges each portion as
it is successfully scanned.
LED
N/A
LED behavior for this indication
is configurable via the feature
"Good Read: When to Indicate"
(see the PRG for information).
Flashes.
N/A
The LED is steadily lit
1
.
The LED blinks continuously.
N/A
LED
LED blinks continuously.
N/A
N/A
Beeper
Scanner beeps four times at
highest frequency and volume
upon power up.
The scanner will beep once at
current frequency, volume,
mono/bitonal setting and
duration upon a successful
label scan.
Scanner sounds one error beep
at highest volume.
Scanner "chirps" six times at
the highest frequency and
current volume.
N/A
N/A
N/A
Beeper
Scanner sounds four low-
frequency beeps.
Scanner sounds three times at
lowest frequency and current
volume.
Scanner sounds one short beep
at highest frequency and
current volume.
17
