PCI-DAS4020/12 User's Guide

Environmental

Operating temperature range
Storage temperature range
Humidity

Power consumption

+5 V Operating (A/D to FIFO)

Connector and pin out

Connector type
Compatible cables (for the 40-pin auxiliary connector)
Compatible accessory products
(with the C40FF-x cable)
Compatible accessory products
(with the C40-37F-x cable)
OR
(with the BP40-37-x and the C37FF-x or C37FFS-x cable)

Auxiliary connector P3 pinout

Pin Signal Name
1 INTERRUPT IN *
3 INTERRUPT ENABLE *
5 Port B 7
7 Port B 6
9 Port B 5
11 Port B 4
13 Port B 3
15 Port B 2
17 Port B 1
19 Port B 0
21 GND
23 n/c
25 GND
27 n/c
29 GND
31 n/c
33 GND
35 +5V
37 GND
39 D/A OUT 0
* Pins 1 and 3 have 10 K pull-up resistors installed.
Table 6-12. Environmental specifications
Table 6-13. Power consumption specifications
Table 6-14. Connector specifications
Table 6-15. Auxiliary connector (P3) pin out
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
6-5
0 to 70 °C
−40 to 100 °C
0 to 90% non-condensing
1.5 A typical, 2.0 A max
BNC connector: five standard female connectors
Auxiliary connector (P3): 40-pin header connector
C40FF-x
C40-37F-x
BP40-37-x
CIO-MINI40
CIO-MINI37
SCB-37
CIO-ERB24
CIO-ERB08
SSR-RACK24
SSR-RACK08
Signal Name
+5V
GND
Port C 7 (A/D Pacer Gate)
Port C 6 (A/D Stop Trigger In)
Port C 5 (Start Trigger In/Ext Clock)
Port C 4
Port C 3
Port C 2
Port C 1
Port C 0
Port A 7
Port A 6
Port A 5
Port A 4
Port A 3
Port A 2
Port A 1
Port A 0
D/A GND
D/A OUT 1
Specifications
