PCI-DAS-TC User's Guide

Linearity error

25 °C to +105 °C
Temperature coefficient
Long term stability
Open thermocouple detect

Power consumption

+5 V operating

Environmental

Operating temperature range
Storage temperature range
Humidity

Main connector and pin-out

Connector type
Compatible cable
Compatible accessory product
(with C37FFS-x cable)
Table 8. Linearity error specifications
0.1 °C typical, 0.35 °C maximum
1 µA/°C typical
0.1 °C / month
On/off switch selectable for each channel, full scale reading
Table 9. Power consumption specifications
887 mA typical, 1441 mA maximum
Table 10. Environmental specifications
0 to 50 °C
20 to 70 °C
0 to 90% non-condensing
Table 11. Main connector specifications
37-pin D-type
C37FFS-x
CIO-STA-TC screw terminal adapter board
17
Specifications
