Summary of Contents for Pace 5111NV
-
Page 1: Installation Guide
INSTALLATION GUIDE HomePortal Intelligent Gateway 5111NV... - Page 2 © 2011 Pace plc. All rights reserved. Pace and the Pace logo are registered trademarks of Pace plc. All other trademarks are the property of their respective owners. Pace provides no warranty with regard to this manual, the software, or other information contained herein, and hereby expressly...
-
Page 3: Table Of Contents
Contents Chapter 1 Introduction ....... . 4 Gathering items for installation ........... . 5 Finding a suitable location . -
Page 4: Chapter 1 Introduction
This all-in-one device includes the modem, router, wireless access point, firewall, and voice gateway. The 5111NV supports ADSL, ADSL2, and ADSL2+ technology. It has four wired Ethernet ports, 802.11b/g/n wireless networking, and voice capabilities. -
Page 5: Gathering Items For Installation
Gathering items for installation To install the gateway, you will need: • Gateway • Power adapter • DSL cable • Ethernet cable (optional), to connect a computer directly to the gateway using a wired connection • Phone cable (optional), for connecting voice telephone service •... -
Page 6: Chapter 2 Installing The Gateway
Installing the Gateway Use the information in this chapter to connect the gateway to the Internet and to your home network. Wireless connection Phone Phone cable Ethernet cable Wired connection Phone cable Phone outlet Power adapter Power outlet To install the gateway, see the following: 1. -
Page 7: Installing Dsl Filters
Installing DSL filters DSL signals are carried over the same lines as regular phone signals. Converting your regular phone line to DSL can cause high-pitched tones and static when you use the phone. To eliminate the noise, you can install DSL filters on every phone or phone device that shares the same phone number as your DSL. -
Page 8: Installing A Dsl Wall Filter
Installing a DSL wall filter To use a DSL filter with a wall-mounted phone, install the DSL filter between the original wall plate and your wall-mounted phone. 1. Lift the phone from the wall pegs, and disconnect the phone cord from the phone jack. -
Page 9: Connecting The Power Adapter
Connecting the power adapter The power adapter supplies power to the gateway. Always use the power adapter that was packaged with the gateway because it matches the power requirements of the gateway and it complies with local requirements. 1. Connect one end of the power adapter to the POWER port on the gateway. 2. -
Page 10: Connecting Devices Using A Wireless Connection
Connecting devices using a wireless connection The gateway has an integrated wireless access point that you can use to connect wireless devices to the gateway. By default, the gateway is configured with a network name (SSID) and WPA-PSK/WPA2-PSK security. 1. On the wireless device, view the available wireless networks. The specifics of how you do this depend on the device you are connecting. -
Page 11: Connecting Phones
If necessary, you can use the gateway configuration page to view or change the gateway settings. On a computer connected to the gateway, enter the following into the address bar of a Web browser: • http://192.168.1.254 You can also use http://gateway.pace.net to access the gateway configuration page. Chapter 2 Installing the Gateway... -
Page 12: Chapter 3 Troubleshooting
Troubleshooting This chapter provides information about common gateway installation issues. If an issue has more than one potential cause, the most common cause is listed first. Connection issues Use the information in this section to identify and resolve issues related to connectivity. -
Page 13: Lan Issues
The Service light blinks • Your Internet service may not be activated. Contact your service provider. The Service light is red • The user name and password may have been entered incorrectly. Verify the user name and password on the gateway configuration page, and try again. •... -
Page 14: Voice Issues
I cannot set a custom encryption key on the gateway user interface • The custom encryption key may not conform with the security mode, key length, key type, or value type. Configure the custom encryption key so that it conforms to the security mode, key length, key type, or value type. -
Page 15: Status Lights
Status lights Use the status lights on the front of the gateway to determine the current state of the gateway. Status light Description Power • Solid green. Power is on. • Red. The gateway is faulty. Ethernet • Solid green. A computer or other device is connected to an ETHERNET port. -
Page 16: Appendix A Regulatory Information
Le présent materiel est conforme aux specifications techniques applicables d'Industrie Canada. Cet appareil numérique de la classe [*] est conforme à la norme NMB-003 du Canada. Manufacturer: 2Wire, Inc. DBA Pace Americas Model(s): 5111NV Part 15 of FCC rules This device complies with part 15 of the FCC Rules and Industry Canada license- exempt RSS standard(s). -
Page 17: Tia 968 (Part 68 Of Fcc Rules)/Ic Cs-03
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •... -
Page 18: Mpe/Sar/Rf Exposure Information
The following sections describe the safety guidelines for this product. AC adapter This product is intended to be supplied with a listed Pace Direct Plug-In AC/DC power adapter marked Class 2 or LPS and rated 12V 3A for all 5111NV-xxx models. -
Page 19: Telecommunication Cord
Article 800 of the NEC. Repairs Do not, under any circumstances, attempt any service, adjustments, or repairs on this equipment. Instead, contact your local Pace Americas distributor or service provider for assistance. Failure to comply may void the product warranty. Location - electrical considerations...
