Data Sheet
Pace offers state-of-the-art gateway
platforms for a wide range of
broadband technologies
Our design teams are totally focused on product quality and work closely with chip set
manufacturers and our factories to ensure we create intelligent, long lasting and future proof
gateways.
The V5500 is Pace's mid-level VDSL2 Gateway, targeted for high-speed Internet services and
triple-play (data, voice and IPTV). It is designed as a flexible platform, which can host a range of
applications and services.
The built-in IEEE 802.11n wireless interface provides coverage and high performance for the
whole home. Four Gigabit Ethernet interfaces are provided to connect PCs, set-top boxes and
other consumer devices in the home. Using the two USB host interfaces, the gateway can be
equipped with 3G backup, hard drives for media storage, ZigBee dongles and other accessories
to extend functionality. Analogue telephones can be connected through the two FXS interfaces.
All of this is controlled by Pace's Helium gateway software, a unified software stack, which
provides secure networking functions, a VoIP PBX as well as a media centre.
The V5500 is equipped with advanced TR-069 management and is interoperable with major
ACSs, as well as other methods of configuration via a user friendly GUI, TFTP or FTP. This
enables operators to easily update the firmware image or configuration data.
V5500 DSL Gateway

Hardware features

WAN Interfaces
• VDSL2
• Profiles 8a/d, 12a/b, 17a and 30a
• Up to 100 Mbps downstream
• ADSL2+, ADSL2 and ADSL
backwards compatible
• Ethernet Port 10/100/1000BaseTX
LAN Interface
• 4 x Ethernet ports 10/100/1000BaseTX
Wi-Fi
• IEEE 802.11 b/g/n
• Optional IEEE 802.11 a/b/g/n
• MIMO 3x3
• Band: 2,4 GHz (opt 2.4 GHz/5 GHz)
• Three internal antennas
USB Port
• 2 x USB 2.0 host
• Connector: Type A female
• 1000 mA power each
