Palmgren 80150 Operating Manual And Parts List

12" bench model drill press

Advertisement

operating manual & parts list
12"
BENCH MODEL DRILL PRESS
Read carefully and follow all safety rules and operating instructions before
first use of this product.
80150
35285.09-1011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 80150 and is the answer not in the manual?

Questions and answers

Summary of Contents for Palmgren 80150

  • Page 1 & parts list 80150 12″ BENCH MODEL DRILL PRESS Read carefully and follow all safety rules and operating instructions before first use of this product. 35285.09-1011...
  • Page 2: Specifications

    Digital readout displays spindle depth and Use soap and water on painted components. RPM. Other features of the Palmgren drill press are an enclosed ball bearing quill assembly, quick belt change and tension mechanism, SPECIFICATIONS positive quick-adjust feed depth stop and a ⁄...
  • Page 3 Palmgren Operating Manual & Parts List 80150 • Use recommended accessories. Refer to page 11. Use of WORK AREA SHOULD BE READY FOR JOB • Keep work area clean. Cluttered work areas and work benches improper accessories may cause risk of injury to persons.
  • Page 4: Installation

    Palmgren Operating Manual & Parts List 80150 INSTALL CHUCK WARNING: Do not permit fingers to touch the terminals of plug when installing or removing from outlet. Refer to Figure 8. • Be sure spindle and chuck tapers are clean and dry. Make sure...
  • Page 5 Palmgren Operating Manual & Parts List 80150 EXTENSION CORDS NOTE: Should the key be removed from the switch at the ON • The use of any extension cord will cause some drop in voltage position, the switch can be turned off but cannot be turned on again.
  • Page 6: Digital Display Panel

    Palmgren Operating Manual & Parts List 80150 Belt Spindle Motor Location A1-5Z B2-5Z A1-4Y C3-5Z B2-4Y A1-3X D4-5Z C3-4Y B2-3X A1-2W 1518 E5-4Y D4-3X 1639 C3-2W 1759 E5-3X 2277 2437 D4-2W Figure 5 – Spindle Speed Adjustment 3386 E5-2W Wood Zinc Diecast Alum.
  • Page 7: Maintenance

    Palmgren Operating Manual & Parts List 80150 • Lower quill assembly (Figure 8, Ref. No. 11) all the way down. MAINTENANCE • Apply lubricant around the inside of the hole in the spindle pulley (Figure 8, Ref. No. 2). WARNING: Turn switch off and remove plug from power source •...
  • Page 8: Troubleshooting

    Palmgren Operating Manual & Parts List 80150 TROUBLESHOOTING SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION Spindle does not turn 1. No power to drill press 1. Check wiring, fuse or circuit breaker 2. Defective switch 2. Replace switch 3. Defective motor 3. Replace motor...
  • Page 9 Palmgren Operating Manual & Parts List 80150 Service Record Palmgren 12″ Bench Model Drill Press DATE MAINTENANCE PERFORMED REPLACEMENT PARTS REQUIRED...
  • Page 10 Palmgren Operating Manual & Parts List 80150 Figure 7 – Repair Parts Illustration for Base...
  • Page 11 Palmgren Operating Manual & Parts List 80150 REPLACEMENT PARTS LIST FOR BASE DESCRIPTION PART NO. QTY. Base 32505.00 8-1.25 x 125mm Hex head bolt 8mm Flat washer 8mm Lock washer 8-1.25mm Hex nut 8-1.25 x 30mm Socket head bolt Column assembly 32506.00...
  • Page 12 Palmgren Operating Manual & Parts List 80150 Figure 8 – Repair Parts Illustration for Spindle and Drive...
  • Page 13 Palmgren Operating Manual & Parts List 80150 REPLACEMENT PARTS LIST FOR SPINDLE AND DRIVE DESCRIPTION PART NO. QTY. Spindle nut 32519.00 Spindle pulley 32520.00 Upper spindle assembly 32521.00 Circlip 32522.00 1/2”-20 Hex nut 12mm Flat washer Cap cover with spring 32523.00...
  • Page 14 Palmgren Operating Manual & Parts List 80150 Figure 9 – Repair Parts Illustration for Head...
  • Page 15 Palmgren Operating Manual & Parts List 80150 REPLACEMENT PARTS LIST FOR HEAD Speed sensor assembly 32543.00 6 x 25mm Spring pin 16109.00 5mm Flat washer 8-1.25 x 8mm Flat point set screw 32572.00 5-0.8 x 10mm Pan head screw 4 x 20mm Spring pin 02817.00...
  • Page 16: Warranty

    • Accessories – 1 year The obligation of Palmgren is limited solely to the repair or replacement, at our option, at its factory or authorized repair agent of any part that should prove deficient. Purchaser must lubricate and maintain the product under normal operating conditions at all times. Prior to oper- ation become familiar with product and the included materials, i.e.
