Windows

If you are using a Windows-based notebook computer, use

the following procedure to change your TCP/IP settings:

1 From the desktop, click Start, and select Settings,

Control Panel, and Network.

2 From the Network control panel, select TCP/IP.

3 From the TCP/IP dialog box, select IP Address.

4 Select "Obtain an IP address automatically."

5 Click OK, and OK again.

6 Restart your computer.

If you are using a Macintosh computer, use the following

procedure to change your TCP/IP settings:

1 From the desktop, select Apple Menu, Control Panels,

and TCP/IP .

2 In the TCP/IP control panel, set Connect Via: to

"Ethernet."

3 In the TCP/IP control panel, set Configure: to "Using

DHCP Server."

4 Close the TCP/IP dialog box, and save your changes.

5 Restart your computer.

Use the following procedure to set up your wired network

computer(s) to communicate with your gateway by

Ethernet cable:

The Connect Via: drop-down list is generated by clicking

the up or down arrows. From the list, select "Ethernet."

The Configure: drop-down list operates in the same way

as the Connect Via: list.

System Settings for Your Computer(s)
