Info Plot Data Source

Displays the name of the file that is the data source for
the Info Plot.

Info Plot - FCS Tab

Show FCS Keyword
FCS Keyword as well as the associated keyword value.
Multiple Keywords can be selected from the scroll box.
Select Clear All Selected

Acquisition Stop and Save

Use Acquisition Stop and Save to terminate the acquisition of a sample at a preset stop value. If there
is more than one stop value set, then the first stop counter reached terminates the current
acquisition.
NOTE
The values set in the Cytometer Control Acquisition Limits (Acquisition Time, Elapsed Time and
Maximum Events) overrides the stop values set here in the event of an acquisition limit being reached
before the Acquisition Stop value has been achieved.
Single Parameter Histograms can be selected for automatic saving in FCS Format.
NOTE
An acquisition from lysed whole blood is to be stopped on 5,000 lymphocytes to allow the collection
and storage of all event data.
773232AH
– Enable this checkbox to display the
to deselect the items.
Using Navios Software 10
Plots Menu
10-111
