User Manual
XDS-2450 Digital Signboard
Quick Start Guide
This printed quick guide provides a quick walkthrough of the set up process. For
complete documentation, please visit
Box Contents
Main Unit
Wi-Fi Antenna
USB Keyboard AND #2
Phillips screwdriver required
System connections
www.digisignage.com
AC Power Adapter
& cord
Quick Start Guide
A USB keyboard required to change system settings.
A #2 Phillips screwdriver is needed to access the DC-in port.
Monopod flex stand
Software Guide
(Select SKUs)
Ethernet Cable
Software CD
(Select SKUs)
Advertisement
Related Manuals for IAdea XDS-2450
Summary of Contents for IAdea XDS-2450
-
Page 1: Quick Start Guide
XDS-2450 Digital Signboard Quick Start Guide This printed quick guide provides a quick walkthrough of the set up process. For complete documentation, please visit www.digisignage.com Box Contents AC Power Adapter Main Unit Ethernet Cable Monopod flex stand & cord Software Guide... - Page 2 Mounting Options and Hardware Installation Option 1: Supplied Monopod flex Option 2: Optional tabletop VESA Option 3: 3 party VESA MIS- stand stand PVK-202 D100/E200 fixtures Installing Wi-Fi antenna and power plug SCREW-MOUNT Wi-Fi REMOVE screw to ATTACH power plug RE-ATTACH plate and tighten screw antenna detach metal plate...
-
Page 3: Content Management
menus or via management software for correct playback times. → using the USB keyboard, select a wireless network and provide security information to connect to your wireless access point → (OPTIONAL) Change Password to prevent access to the menus. IMPORTANT A password is not present by default. Setting a password will hide the menus even if a USB keyboard is plugged in. - Page 4 Frequently Asked Questions When I have wireless configured and Ethernet wire connected, which path (wired or wireless) is data sent? The wired Ethernet connection takes precedence over the wireless when both are available. As soon as you unplug the network wire, the system attempts to reconnect via wireless network. How do I know if my wireless is properly connected? On player boot up, it attempts to obtain an IP address from your router via the wireless link.
