- Page 1 XDS-2450 User’s Manual...
-
Page 2: Table Of Contents
Mounting Options and Hardware Installation Menu setup USB keyboard configuration menus Navigating the menus Connect the XDS-2450 to your network Clock and calendar settings Adjusting picture and sound (disabling the on-screen key lock) Muting the picture and sound Setting a password... -
Page 3: Introduction
Introduction This document describes the hardware and software operations of the XDS-2450, system set up, and frequently asked questions. Features 24-inch MVA panel widescreen LCD display for portrait or landscape display Built-in wireless b/g/n (2.4GHz only) and Ethernet connectivity ... -
Page 4: Configuring The Xds-2450
Configuring the XDS-2450 Mounting Options and Hardware Installation Option 1: Supplied Option 2: Optional tabletop Option 3: 3 party VESA Monopod Flex Stand VESA stand PVK-202 MIS-D100/E200 fixtures Installing Wi-Fi antenna and power plug SCREW-MOUNT Wi-Fi REMOVE screw to ATTACH power plug... -
Page 5: Usb Keyboard Configuration Menus
USB keyboard configuration menus You must attach a USB keyboard to the XDS-2450 to configure settings. With the player booted up and ready, it takes approximately 30 seconds after you plug in the keyboard for the following menu to be displayed: Navigating the menus Navigate the menus using arrow keys, space bar, enter key, ESC, and numeral keys on your USB keyboard. -
Page 6: Clock And Calendar Settings
Proceed to configure an available static IP address. Please ask your network administrator for assistance if necessary Clock and calendar settings Time and Time Zone must be set correctly for scheduled playback. Highlight “Time setting” and press “Enter” on keyboard to <Select> ... -
Page 7: Muting The Picture And Sound
Muting the picture and sound Keep the player in operation for testing or updates while reducing power consumption and unwanted sound Optional remote accessory (PRC-100) is also available for remote adjustment of this setting 1. Disable key lock (MENU-↑-↓-↑-↓-MENU) if engaged 2. -
Page 8: Content Management
Working with SMIL The XDS-2450 uses open communications protocols for highly flexible content presentation and playback control. SMIL-compliance means predictable results across multiple devices, and SMIL’s non-proprietary nature means that your investments are never obsolete. -
Page 9: Technical Data
Technical Data Specifications XDS-2450 Display and Sound 24” 16:9 MVA TFT LCD panel 250 nits brightness 1920x1080 Full HD panel resolution Built-in stereo speakers 2Wx2 Video format support POPAI Screen Media Standards: S6 (MPEG-1 SIF, 3Mbps CBR) S7 (MPEG-1 480p, 10Mbps CBR) - Page 10 Environmental Operating temperature: 0 – 40° C / 32 – 104° F Humidity: 5 – 85% @ 40° C / 32 – 104° F non-condensing Dimensions (WxHxD) 576x344x69 (mm) / 22.7x13.5x2.7 (inches) Weight 5 Kg / 11.0 pounds Safety UL-approved/PSE (Japan) certified AC adapter Certifications CE/FCC/RoHS Warranty...
-
Page 11: Appendix: Faq
What is the maximum file size for a single video file? The maximum video file size for the XDS-2450 is 2GB. We recommend reserving a safety margin to avoid exceeding the limit (i.e. limiting files to 1850MB).
