Heat & Glo COSMO42-IFT Owner's Manual
  1. Manuals
  2. Brands
  3. Heat & Glo Manuals
  4. Indoor Fireplace
  5. COSMO42-IFT
  6. Owner's manual

Heat & Glo COSMO42-IFT Owner's Manual

Hide thumbs Also See for COSMO42-IFT:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT discard this manual!
Models:
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fitter.
See appliance installation manual for additional
Commonwealth of Massachusetts requirements.
Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner's Manual • 2491-981 Rev. B • 11/17
Owner's Manual

Care and Operation

WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COSMO42-IFT and is the answer not in the manual?

Questions and answers

Related Manuals for Heat & Glo COSMO42-IFT

Summary of Contents for Heat & Glo COSMO42-IFT

  • Page 1: Care And Operation

    In the Commonwealth of Massachusetts installation must be performed by a licensed plumber or gas fitter. See appliance installation manual for additional Commonwealth of Massachusetts requirements. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 2: Welcome

    00,000 00,000 MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial XXXXXXXX XXXXXXXX ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX (Serie): (Serie): Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 3: Table Of Contents

    C. Contact Information ......32  = Contains updated information. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 4: Limited Lifetime Warranty

    Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645H 10/15 Page 1 of 2 Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...
  • Page 5 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645H 10/15 Page 2 of 2 Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 6: Product Specific Information

    23,500 17,500 .057 (0-2000 FT (PROPANE) HHT Factory Trained or NFI certified professionals. COSMO32-IFT 19,000 13,250 (0-2000 FT) (NG) COSMO32-IFT 1.25 16,500 12,750 (0-2000 FT) (PROPANE) Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 7: Important Safety And Operating Information

    Call a qualified service from hot surfaces. technician to service the appliance. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 8: General Operating Parts

    Use appropriate finishing materials that are able to withstand these conditions. For additional finishing guidelines, see Section 10 in the appliance Installation Manual. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...
  • Page 9 Sugges ons on how to further reduce TV temperatures: Increase “A” dimension. Increase “C” dimension, however, increasing “B” dimension beyond maximum recommended typically results in higher temperatures. Figure 3.4 Good Faith TV Guidelines Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...
  • Page 10 5. “C” dimension taken from top of appliance opening to ceiling. Figure 3.5 Good Faith TV Guidelines- Smart-Wall™ TV Heat Management Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 11: Before Lighting Appliance

    • Ensure that the glass is sealed and in the proper position and that the integral barrier is in place. WARNING! Risk of Fire or Asphyxiation! DO NOT op- erate fireplace with fixed glass assembly removed. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 12: Lighting Instructions (Ipi)

    Propane Installation code, CSA B149.1. tions accompanying appliance. For additional information on operating your 593-913i Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 13: Appliance Break-In

    The Heat-Duct heat management option is available for use with the COSMO42-IFT and COSMO32-IFT appliances. The Heat-Duct redistributes heat from the fireplace via the furnace ductwork. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 14: Operation During A Power Outage - Intellifire™ Touch

    • Slide the ON/REMOTE/OFF switch to the ON position. NOTICE: Some functionality will be lost when using battery backup including fan, lights, or any other auxiliary functions that require household 110-120 VAC power. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 15: Detailed Component Operating Instructions - Intellifire™ Touch

    - Set the IFT-ECM 3-position selector switch to Climate function of the fireplace. This function lights OFF position. the pilot flame ONLY to provide enough heat in the Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...
  • Page 16 RC400 remote error condition was corrected. control. - If the IFT-ECM re-enters the lock-out condition after these steps, call your dealer for service. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 17: Maintenance And Service

    • Carefully set fixed glass assembly in place on fireplace. off and cooled before servicing. Hold glass in place with one hand and secure glass latches with the other hand. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...
  • Page 18 WARNING! Risk of Explosion! Risk of Asphyxiation! Glass latches MUST be properly engaged. Inspect glass seal before installing decorative front. Gas could leak! 5. Reinstall decorative front. Figure 4.1 Fixed Glass Assembly Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 19: Maintenance Tasks - Qualified Service Technician

    If not using your fireplace for an extended period of time (summer months, vacations/trips, etc), to prevent unin- tended operation: • Remove batteries from remote controls. • Unplug 6 volt adapter plug on IPI models. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...
  • Page 20 • Verify that there is not a short in flame sense circuit by checking continuity between pilot hood and flame sensing rod. Replace pilot as necessary. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 21: Frequently Asked Questions And Troubleshooting

    Installer’s Manual for this the touch. appliance. Contact your dealer for additional information regarding operation and troubleshooting. Visit www.heatnglo.com to locate a dealer. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 22: Frequently Asked Questions - Intellifire™ Touch Controls (Ift-Rc400) (Optional Remote)

    Verify home circuit breaker is on and master reset is on (if No power to appliance. message on-screen: equipped). “Remote Control Communication Power outage. Install new batteries in battery backup. Error.” Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 23: Troubleshooting

    If open or shorted, replace valve. Check valve harness wire continuity, if open replace 6-pin harness. Pilot won’t light, there is no noise Spark coil failure. Replace ECM. or spark, 2 Red/2 Green Lockout. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...
  • Page 24 Damaged pilot assembly. IFT- sistance between tip of sense rod and ECM connector, should be less than 1 ohm. Replace pilot assembly if damage is detected. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 25: Reference Materials

    • Install a switch lock or a wall/remote control with child protection lockout feature. • Keep remote controls out of reach of children. See your dealer if you have questions. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 26: Service Parts

    GLA-32HNG Lower Panel 2492-103 Valve Assembly Refer to Valve Page Junction box 4021-013 Heat Shield, Components 2493-129 Additional service part numbers appear on following page. 11/17 Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...
  • Page 27 2326-134 8.15 Harness, IFT 6 Pin Wiring 2326-132 Ori ce NG (#45C) 582-845 Ori ce LP (1.25C) 582-8125 Additional service part numbers appear on following page. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 28: Service Parts

    Thermostat Wire 2118-170 NGK-32LINEAR Conversion Kit NG Conversion Kit LP LPK-32LINEAR Pilot Ori ce NG 593-528 Pilot Ori ce LP 593-527 Regulator NG NGK-DXV-50 Regulator LP LPK-DXV-50 Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...
  • Page 29 Valve Assembly Refer to Valve Page Junction box 4021-013 Heat Shield, Junction Box 2491-129 Heat Shield, Components 2493-129 Additional service part numbers appear on following page. 11/17 Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...
  • Page 30 2326-134 9.15 Harness, IFT 6 Pin Wiring 2326-132 Ori ce NG (#42C) 582-842 Ori ce LP (.057C) 582-057 Additional service part numbers appear on following page. Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...
  • Page 31 Thermostat Wire 2118-170 Conversion Kit NG NGK-42LINEAR Conversion Kit LP LPK-42LINEAR Pilot Ori ce NG 593-528 Pilot Ori ce LP 593-527 Regulator NG NGK-DXV-50 Regulator LP LPK-DXV-50 Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...

  • Page 32: Contact Information

    5941237, 6006743, 6019099, 6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729, 8147240 or other U.S. and foreign patents pending. 2000-945C Printed in U.S.A. - Copyright 2017 Heat & Glo • COSMO42-IFT, COSMO32-IFT Owner’s Manual • 2491-981 Rev. B • 11/17...
