This parameter set to 4 option "ONPUT 1" "OUTPUT 2" "ALL" "OFF", When moving
object is detected and turn on the tracking function, it will operate the linkage
switch according to the setting, and after dome camera back to preset location, the
auxiliary switch will turn off automatically.
F3. SET TRACKING AREA LEFT BOUNDARY
When the regional tracking function turns on, this parameter is to set the area
left boundary. When the moving object cross this boundary, camera will stop
automatically and back to preset surveillance location
F4. SET TRACKING AREA RIGHT BOUNDARY
When the regional tracking function turns on, this parameter is to set the area
right boundary. When the moving object cross this boundary, camera will stop
automatically and back to preset surveillance location
F5. REGION TRACKING FUNCTION
This parameter is divided into "ON" "OFF", turn on/off the regional tracking function.
G. TRACKING FUNCTION
This parameter is divided into "ON" "OFF", turn on/off the auto tracking function.
2. CROSS ALARM FUNCTION
Function Overview:
Mainly used in monitoring alarm area , it will activate alarm when objects go across
the cordon, suitable for real-time monitoring of important occasions. .
Operation Instruction:
-------------------------------------------
A. LINE IS NOT SET
Important information: please set the cordon before the function used and make
sure the cordon use POINT 1 as monitoring area , the cordon must be set in POINT 1.
B. POINT 1 SET
Move the cursor , choose the location of asterisk( * ) to set POINT 1
C. POINT 2 SET
Move the cursor , choose the location of asterisk( * ) to set POINT 2
D. DELETE
Used to delete the set cordon.
E. ALARM OUTPUT
There are "output 1" "output 2" "all" "close" 4 options , the alarm function will be
20
VIDEO ANALYSIS
<AUTO TRACKING >
<CROSS ALARM >
<LOSS DETECT >
DELAY TIME: 05
DSP ENABLE: OFF
BACK
EXIT
CROSS ALARM SET
-------------------------------------------
—LINE IS NOT SET—
< POINT1 SET >
< POINT2 SET >
DELETE
ALARM OUT ： OFF
DETECT SIZE ： 2
ENABLE
： OFF
BACK
EXIT
